ELECTRICAL PART LIST
Resistors (continued)
ESP-88 Chassis 4x4 PCB Assembly
Reference
Designator
Description Vendor
Name
Vendor Part Number Note
R316 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R317 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R318 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R319 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R320 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R321 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R322 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R323 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R324 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4
R325 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4
R326 8.2K, 0603, 1/10W, 1% Yageo RC0603FR-078K2 4
R327 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R328 5.6K, 0603, 1/10W, 1% Yageo RC0603FR-075K6 4
R329 3.3K, 0603, 1/10W, 1% Yageo RC0603FR-073K3 4
R330 8.2K, 0603, 1/10W, 1% Yageo RC0603FR-078K2 4
R331 1.5K, 0603, 1/10W, 1% Yageo RC0603FR-071K5 4
R332 2.2K, 0603, 1/10W, 1% Yageo RC0603FR-072K2 4
R333 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K 4
R334 2.7K, 0603, 1/10W, 1% Yageo RC0603FR-072K7 4
R336 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7 4
R337 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R338 16K, 0603, 1/10W, 1% Yageo RC0603FR-0716K 4
R339 18 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0718R 4
R340 18 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0718R 4
R341 18 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0718R 4
R342 18 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0718R 4
R343 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R344 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R345 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R346 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R347 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R348 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R349 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R350 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R351 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R352 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R353 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R354 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K 4
R355 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4
R356 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R 4
R357 8.2K, 0603, 1/10W, 1% Yageo RC0603FR-078K2 4
R358 6.8K, 0603, 1/10W, 1% Yageo RC0603FR-076K8 4
R359 5.6K, 0603, 1/10W, 1% Yageo RC0603FR-075K6 4
R360 3.3K, 0603, 1/10W, 1% Yageo RC0603FR-073K3 4
R361 8.2K, 0603, 1/10W, 1% Yageo RC0603FR-078K2 4
R362 1.5K, 0603, 1/10W, 1% Yageo RC0603FR-071K5 4
R363 2.2K, 0603, 1/10W, 1% Yageo RC0603FR-072K2 4
