Bose ControlSpace ESP-88 User Manual

61
ELECTRICAL PART LIST
Diodes (continued)
Inductors
Transistors
CC-64 Control Center
Reference
Designator
Description Vendor
Name
Vendor Part
Number
D339 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D340 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D341 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D342 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D343 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D344 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D345 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D346 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D347 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D348 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D349 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D350 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D351 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D352 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D353 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D354 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D355 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D356 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D357 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D358 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D359 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D400 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D401 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D402 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D403 LED, GREEN, SMD, 0805 Everlight
17-21 VGC/TR8
4
D500 TVSSMAJ5.0CA-TR, SMA, ST ST
SMAJ5.0CA-TR
4
D501 TVSSMAJ5.0CA-TR, SMA, ST ST
SMAJ5.0CA-TR
4
Reference
Designator
Description Vendor
Name
Vendor Part
Number
L200 10-BASE T LOW PASS FILTER YCL
20F001N
4
L200 10-BASE T LOW PASS FILTER BEL-FUSE
A556-2006-02
4
L201 CHIP, EMI FILTER, 50V/2A, 20% Panasonic
EXCCET103U
4
L202 CHIP, EMI FILTER, 50V/2A, 20% Panasonic
EXCCET103U
4
L502 CHIP, EMI FILTER, 50V/2A, 20% Panasonic
EXCCET103U
4
L503 CHIP, EMI FILTER, 50V/2A, 20% Panasonic
EXCCET103U
4
Reference
Designator
Description Vendor
Name
Vendor Part
Number
Q100 PNP, 50V, 100mA, SOT-23 KEC
KRA102S
4
Q101 PNP, 50V, 100mA, SOT-23 KEC
KRA102S
4
Q102 PNP, 50V, 100mA, SOT-23 KEC
KRC102S
4
Q103 PNP, 50V, 100mA, SOT-23 KEC
KRA102S
4
Q202 PNP, 60V, 1A, SOT-89, KTA1668 KEC
KTA1668Y
4
Q500 PNP, 50V, 100mA, SOT-23 KEC
KRC102S
4
