Bose ControlSpace ESP-88 User Manual

74
TEST PROCEDURES
Table of connection between the ESP-88 and AuBit switcher
Caution ! COM-L and COM-R shall be connected with “Phantom cutter”.
ESP-88 Chassis Configuration for test
Switcher
Outputs
ESP-88 ESP-88 Switcher Inputs
OUT CH1 Slot1 Input CH1 IN CH1 Slot2 Output CH1
OUT CH2 Slot1 Input CH2 IN CH2 Slot2 Output CH2
OUT CH3 Slot1 Input CH3 IN CH3 Slot2 Output CH3
OUT CH4 Slot1 Input CH4 IN CH4 Slot2 Output CH4
OUT CH5 Slot3 Input CH1 IN CH5 Slot4 Output CH1
OUT CH6 Slot3 Input CH2 IN CH6 Slot4 Output CH1
OUT CH7 Slot3 Input CH3 IN CH7 Slot4 Output CH1
OUT CH8 Slot3 Input CH4 IN CH8 Slot4 Output CH1
OUT OPT-1L NC IN OPT-1L NC
OUT OPT-1R NC IN OPT-1R NC
OUT OPT-2L Phantom Checker CHA IN OPT-2L 600ohm Load
OUT OPT-2R Phantom Checker CHB IN OPT-2R 600ohm Load
COM-L ATS-2 Analog Output A COM-L ATS-2 Analog Input A
COM-R ATS-2 Analog Output B COM-R ATS-2 Analog Input B
ESP Slot Card Description
GIO2 Blank Empty slot
GIO1 GIO With 2.2k ohm Loop back cable.
DSP DSP Main Card Main card only - no expansion card
IO Slot 1 4x4 Main card MIC/Line Input card
IO Slot 2 4x4 Output card Line output card
IO Slot 3 4x4 Main card MIC/Line Input card
IO Slot 4 4x4 Output card Line output card
IO Slot 5 Blank Empty slot
IO Slot 6 Blank Empty slot
IO Slot 7 Blank Empty slot
IO Slot 8 Blank Empty slot
