Technical Information
English • 29Installation & Operation Guide • EX-440C/1280/1280C/12AEC
PRO.BOSE.COM
Control Inputs
Inputs & Connectors 5 analog or digital inputs, 2 kΩ internal pull-up resistor to 5 V, 3.81 mm,
6-pin Euroblock
Voltage Range Analog Inputs: 0 V to 3.3 V (maximum: 5 V)
Digital Inputs: 0 V to 3.3 V (threshold voltage: 1.6 V)
Control Outputs
Outputs & Connectors 5 digital outputs, 3.81 mm, 6-pin Euroblock
Output Voltage High: 8 V (open circuit), 2.5 V at 10 mA
Low: < 1 V at 100 mA, push-pull
Indicators & Controls
Display 256 × 64 OLED with rotary/push encoder
LED Status Indicators Power/Status
Audio Signal Indication On display
Electrical
Mains Voltage 100 VAC to 240 VAC, 50/60 Hz
AC Power Consumption 35 W typical at 40 °C (104 °F) ambient
Mains Connector IEC 60320-C14 (inlet)
Power Dissipation 60 W (205 BTU, 52 kcal)
Physical
Dimensions (H × W × D) 44 mm × 483 mm × 282 mm (1.7 in × 19.0 in × 11.1 in)
Net Weight 3.2 kg (7.1 lb)
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Cooling System 2 variable-speed fans, side venting
General
PC Configuration Software ControlSpace Designer
Network Control Ethernet (RJ-45), 1 Gbps
RS-232/485 Ports RS-232 (DTE) & Bose CC-16 (RS-485 master); 3.81 mm, 3-pin Euroblock
