Bose ControlSpace EX-1280 User Manual

Technical Information
34 • English EX-440C/1280/1280C/12AEC • Installation & Operation Guide
PRO.BOSE.COM
EX-12AEC
Integrated DSP
Signal Processor 32-bit fixed/floating-point DSP 456 MHz/Arm Cortex-A8 600 MHz
Maximum Calculation 3.6 GIPS / 2.7 GFLOPS
Delay 43 s
Sample Rate 48 kHz
Acoustic Echo Cancellation
Tail Length 480 ms
Noise Reduction 32 dB
Latency 50 ms
Channels 12
References 4
Audio Over IP
Dante 16 × 16, primary/secondary, routable to AEC
Indicators & Controls
Display 256 × 64 OLED with rotary/push encoder
LED Status Indicators Power/Status
Audio Signal Indication On display
Electrical
Mains Voltage 100 VAC to 240 VAC, 50/60 Hz
AC Power Consumption 35 W typical at 40 °C (104 °F) ambient
Mains Connector IEC 60320-C14 (inlet)
Power Dissipation 60 W (205 BTU, 52 kcal)
Physical
Dimensions (H × W × D) 44 mm × 483 mm × 282 mm (1.7 in × 19.0 in × 11.1 in)
Net Weight 2.4 kg (5.3 lb)
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Cooling System 2 variable-speed fans, side venting
General
PC Configuration Software ControlSpace Designer
Network Control Ethernet (RJ-45), 1 Gbps

Bose ControlSpace EX-1280 Specifications

General

Frequency range	18 - 20000 Hz
Channels quantity	20 channels
Product color	Black
Rack capacity	1U
Rack mounting	Yes
LED indicators	Power
Audio input	3.81 mm detachable Euroblock, 6-pin
RS-232 ports	1
USB connector type	Micro-USB B, USB Type-A
Standard interfaces	USB
Ethernet LAN (RJ-45) ports	3
Microphone included	No
DC input voltage	230 V
Power consumption (typical)	35 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	282 mm
Width	483 mm
Height	44 mm
Weight	3200 g
