Bose ControlSpace SP-24 Service Manual

25
ELECTRICAL PART LIST
Inductors and Ferrite Beads
Capacitors (continued)
Input/Output PCB Assembly
Diodes
Reference
Desi
g
nator
Description
V
endo
r
Part Number Note
CT708 10uF, CE, 25V, 20%, RLT, 5X11 157E-106M+K-IU 4
CT717 100uF, CE, 25V, 20%, GS, RLT, 6.3X11 157E-107M+K-LUG 4
CT718 100uF, CE, 25V, 20%, GS, RLT, 6.3X11 157E-107M+K-LUG 4
CT719 100uF, CE, 25V, 20%, GS, RLT, 6.3X11 157E-107M+K-LUG 4
Reference
Desi
g
nator
Description
V
endo
r
Part Number Note
L701 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L702 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
L703 FERRITE, BEAD, INDUCTOR, BL01RN1A1F1J 1808-0680+0 4
Reference
Desi
g
nator
Description
V
endor Part Number Note
D601 BAV99, SOT23, PHILIPS 4840-8970+3 4
D602 BAV99, SOT23, PHILIPS 4840-8970+3 4
D603 BAV99, SOT23, PHILIPS 4840-8970+3 4
D604 BAV99, SOT23, PHILIPS 4840-8970+3 4
D701 BAV99, SOT23, PHILIPS 4840-8970+3 4
D702 BAV99, SOT23, PHILIPS 4840-8970+3 4
D703 BAV99, SOT23, PHILIPS 4840-8970+3 4
D704 BAV99, SOT23, PHILIPS 4840-8970+3 4
D705 BAV99, SOT23, PHILIPS 4840-8970+3 4
D706 BAV99, SOT23, PHILIPS 4840-8970+3 4
D707 BAV99, SOT23, PHILIPS 4840-8970+3 4
D708 BAV99, SOT23, PHILIPS 4840-8970+3 4
D800 LL4148, SM 4804-1480+3 4
D801 LL4148, SM 4804-1480+3 4
D802 LL4148, SM 4804-1480+3 4
D803 LL4148, SM 4804-1480+3 4
Transistors
Reference
Desi
g
nator
Description
V
endor Part Number Note
Q701N MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020+3 4
Q702N MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020+3 4
Q704 MPSA06, VCE, 80V, NS, RL
T
4860-8890+K 4
Q705 MPS, A56, VCE, 80V, NS, RLT 4860-8910+K 4
Q706 MPSA06, VCE, 80V, NS, RLT 4860-8890+K 4
Q707 MPS, A56, VCE, 80V, NS, RLT 4860-8910+K 4
Q708 MPSA06, VCE, 80V, NS, RL
T
4860-8890+K 4
Q709N MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020+3 4
Q800 MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020+3 4
Q801 MOSFE
T
, N-CH, 60V, 115MA, 2N7002,
SO
T
-23, SM
4907-0020+3 4
