Bose ControlSpace SP-24 Service Manual

26
ELECTRICAL PART LIST
Input/Output PCB Assembly
Transistors (continued)
Integrated Circuits
Miscellaneous
Reference
Desi
g
nator
Description
V
endor Part Number Note
Q802 MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020+3 4
Q803 MOSFET, N-CH, 60V, 115MA, 2N7002,
SOT-23, SM
4907-0020+3 4
Q804 MPSA06, VCE, 80V, NS, RLT 4860-8890+K 4
Q805 MPS, A56, VCE, 80V, NS, RLT 4860-8910+K 4
Reference
Desi
g
nator
Description
V
endo
r
Part Number Note
U202 MCU,
A
T90USB162-16AU, TQFP3
2
3132-8221+0 4
U701 NJM2068M-#ZZZB, DUAL O
P
A
MP 3130-6890+0 4
U702 NJM2068M-#ZZZB, DUAL O
P
A
MP 3130-6890+0 4
U703 NJM2068M-#ZZZB, DUAL O
P
A
MP 3130-6890+0 4
U704 NJM2068M-#ZZZB, DUAL O
P
A
MP 3130-6890+0 4
Reference
Desi
g
nator
Description
V
endor Part Number Note
CR1 SURGE, PROTECTOR, 500V, 603 2706-0004+0 4
CR2 SURGE, PROTECTOR, 500V, 603 2706-0004+0 4
J201 JACK, USB, 4P, 90DEG 2113-3212+0 4
J202 WAFER, 8
P
, P2.5, ST. 2102-081S+004 4
J203 HEADER, 2X3P, P2.54, ST, MALE 2101-3124+0 4
J601 SOCKET, XLR, 3
P
, 50V, 6A, NC3FAH2, NEUTRIK 2113-3331+0 4
J602 SOCKET, XLR, 3
P
, 50V, 6A, NC3FAH2, NEUTRIK 2113-3331+0 4
J701 SOCKET, XLR, 3P, MALE, AC3MAH2-AU, AMPHENOL 2113-3159+0 4
J702 SOCKET, XLR, 3P, MALE, AC3MAH2-AU, AMPHENOL 2113-3159+0 4
J703 SOCKET, XLR, 3P, MALE, AC3MAH2-AU, AMPHENOL 2113-3159+0 4
J704 SOCKET, XLR, 3P, MALE, AC3MAH2-AU, AMPHENOL 2113-3159+0 4
J705 HEADER, IDC, 30P, 2XP2.54, 3510 SERIES 2101-3122+0 4
J706 WIRE-CON, 3P, P7.5/5.0, #26, UL1007, L150, RD/WH,
F/M
7012-7550+1 4
J707 2P, ST.WAFER, P=2.5, COULOMB 2102-021S+004 4
JP601 SHUNT, 2P, P=2.54 2101-0661+0 4
JP601 WAFER, 2PIN, P=2.54, ST, 6MM 2101-1494+0 4
JP602 SHUNT, 2P, P=2.54 2101-0661+0 4
JP602 WAFER, 2PIN, P=2.54, ST, 6MM 2101-1494+0 4
K1 RELAY, 2P2T, 12V, 140MM,
A
-12W-K, TAKAMISAWA 4500-0490+0 4
K2 RELAY, 2P2T, 12V, 140MM,
A
-12W-K, TAKAMISAWA 4500-0490+0 4
K3 RELAY, 2P2T, 12V, 140MM,
A
-12W-K, TAKAMISAWA 4500-0490+0 4
K4 RELAY, 2P2T, 12V, 140MM,
A
-12W-K, TAKAMISAWA 4500-0490+0 4
T1 BRACKET-GROUNDING, PCB, SPCC,
BSMPEXPO+05CS11
4132-6221+1 4
Y200 CRYSTAL, 8MHZ, HC-49/U-S 2300-2990+0 4
