ELECTRICAL PART LIST
Switch Mode Power Supply (SMPS) PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C3 222M, 1KV, PIN=5 17C-222KLA 4
C4 22uF, 50V, 5x11, +/-20% 17A-220M7B 4
C5 100nF, 50V, 1206, X7R 17S-104M72 4
C6 68pF, 50V, 0805, X7R 17B-680J71 4
C7 1nF, 0805, SMD, 50V, X7R 17B-102K71 4
C8 1nF, 1206, SMD, 250V, X7R 17S-102KD1 4
C9 680uF, 25V, 10x16, +/-20%, Low ESR 17A-681M4B 4
C10 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C11 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C12 1000pF, 1206, SMD, 630V, X7R 17S-101KK1 4
C13 100nF, 0805, SMD, X7R 17B-104K71 4
C14 1nF, 1206, SMD, 250V, X7R 17S-102KD1 4
C15 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C16 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C17 680uF, 25V, 10x16, +/-20%, Low ESR 17A-681M4B 4
C18 680uF, 25V, 10x16, +/-20%, Low ESR 17A-681M4B 4
C19 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C20 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C21 1000uF, 16V, 10x16, +/-20%, Low ESR 17A-102M3B 4
C22 1000uF, 16V, 10x16, +/-20%, Low ESR 17A-102M3B 4
C23 680uF, 25V, 10x16, +/-20%, Low ESR 17A-681M4B 4
C24 47uF, 50V, 6x12, +/-20% 17A-470M7B 4
C25 1nF, 0805, SMD, 50V, X7R 17B-102K71 4
C26 100nF, 0805, SMD, X7R 17B-104K71 4
C27 1000pF, 1206, X7R, SMD, 630V 17S-101KK1 4
C28 100nF, 0805, X7R, SMD 17B-104K71 4
C29 100nF, 0805, X7R, SMD 17B-104K71 4
C30 100nF, 0805, X7R, SMD 17B-104K71 4
C31 100nF, 0805, X7R, SMD 17B-104K71 4
C32 100nF, 0805, X7R, SMD 17B-104K71 4
C33 100nF, 0805, X7R, SMD 17B-104K71 4
C34 47nF, 0805, X7R, SMD, 50V 17B-473M4B 4
C35 100nF, 0805, X7R, SMD 17B-104K71 4
C36 100nF, 0805, X7R, SMD 17B-104K71 4
C37 100nF, 0805, X7R, SMD 17B-104K71 4
C38 1nF, 1206, X7R, SMD, 250V 17S-102KD1 4
C39 100nF, 0805, X7R, SMD 17B-104K71 4
C40 100nF, 0805, X7R, SMD 17B-104K71 4
C41 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C42 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
C43 220uF, 25V, 8x12, +/-20%, Low ESR 17A-221M4B 4
To Next Page
