Bose ControlSpace SP-24 Service Manual

31
ELECTRICAL PART LIST
Switch Mode Power Supply (SMPS) PCB Assembly
Diodes
Transistors
Inductors
Reference
Designator
Description Vendor Part
Number
Note
LF1 25mH (Vdson (HZ) Electronics Co. model
VD0880)
UD0880 3, 4
L1 22Uh GL0603-220J 4
L2 4.7uH, 3A DR0710-4R7M-D180 4
L3 4.7uH, 3A DR0710-4R7M-D180 4
L5 10uH, 1A DR0608-100M-D182 4
L6 3.3uH, 3A ISO-359K01-L01 4
Reference
Designator
Description Vendor Part
Number
Note
ZD1 SMD, 15V, 1/2W, SOD-8 12S-15V02E 4
ZV1 7N471K 15V-07N471 3, 4
D1 UF108, 1A, 800V, D0-41 12H-UF108E 4
D2 UF108, 1A, 800V, D0-41 12H-UF108E 4
D3 UF108, 1A, 800V, D0-41 12H-UF108E 4
D4 UF108, 1A, 800V, D0-41 12H-UF108E 4
D5 FR104, 1A, 400V, D0-41 12H-FR104E 4
D6 UF108, 1A, 800V, D0-41 12H-UF108E 4
D7 FR104, 1A, 400V, D0-41 12H-FR104E 4
D8 SMD, 1N4148, SOD-8 12S-41480E 4
D9 UF204, 2A, 400V, D0-201AD 12H-UF204E 4
D10 UF204, 2A, 400V, D0-201AD 12H-UF204E 4
D11 FR104, 1A, 400V, D0-41 12H-FR104E 4
D12 SR1660CT, 16A, 60V, T0-220AB 12B-R1660P 4
D12 23.2x16x25mm 53E-000601 4
D12 3mm 62S-000100 4
D12 3x8mm 60M-B0308N 4
D13 1N4148, D0-35 12T-41480E 4
D14 FR104, 1A, 400V, D0-41 12H-FR104E 4
Reference
Designator
Description Vendor Part
Number
Note
Q1 MOSFET, SSS4N60, 4A, 600V, T0-220F,
FAIRCHILD
13M-S4N60C 4
Q2 2N5551, T0-92 13T-2N555D 4
