ELECTRICAL PART LIST
Switch Mode Power Supply (SMPS) PCB Assembly
Miscellaneous
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Note
U1 NCP1200DR2, f=60KH, SOP-8 11S-P1200G 4
U2 KIA431B, 2.5V +/-1%, T0-220, KEC 11W-A431BA 4
U3 LM7812, 12V, T0-220, FAIRCHILD 11W-M7812B 4
U4 KA7912, 12V, T0-220, FAIRCHILD 11W-A7912B 4
U5 LDO, LM1084, 5V, T0-220, FAIRCHILD 11W-N1084B 4
U6 LDO, LM1084, 5V, T0-220, FAIRCHILD 11W-N1084B 4
Reference
Designator
Description Vendor Part
Number
Note
MCR1 MCR100-6, T0-92 13K-R1006E 4
NTC1 5D-9 (5 Ohms) 15H-5D900M 3, 4
PC1 EL817, DIP-4 (Sharp type PC817, Everlight
type EL817or Lite-on type LTV-817)
11B-EL817Y 3, 4
T1 ER28H (Vdson (HZ) Electronics Co.,
VD0935, ER28. Model VP330A (North
America only)
22P-VD0935-L1 3, 4
F1 T1.6A, 250V, WICKMANN (Wickman type
372 or Ever Island type 2000)
31T-130JTA 3, 4
J1 0.6x15 32L-006150 4
J2 0.6x10 32L-006100 4
J3 0.6x7.5 32L-006075 4
J4 0.6x7.5 32L-006075 4
J5 0.6x18 32L-006180 4
J6 0.6x18 32L-006180 4
J7 0.6x10 32L-006100 4
J8 0.6x10 32L-006100 4
XS1 2 PIN, 7.92mm, VH (EI Dupont 101F or Kolon
Industries KN3321V0)
33U-027921 3, 4
XS2 2 PIN, 2.54mm, PH 33U-022540 4
XS3 2 PIN, 2.54mm, PH 33U-022540 4
XS4 8 PIN, 2.54mm, PH 33U-082540 4
XS5 6 PIN, 2.54mm, PH 33U-062540 4
