52 - Installation Guide
Factory Default Settings
Channel Parameter Mixer Stereo Dual Mono Parameter Range
Input 1
Bass 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Treble 0 dB 0 dB 0 dB -6 dB ~ +6 dB
AGC Enable N N N
Input 2 Bass 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Treble 0 dB 0 dB 0 dB -6 dB ~ +6 dB
AGC Enable N N N
Input 3 Bass 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Treble 0 dB 0 dB 0 dB -6 dB ~ +6 dB
AGC Enable N N N
Input 4 Bass 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Treble 0 dB 0 dB 0 dB -6 dB ~ +6 dB
AGC Enable N N N
Page Input Bass 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Treble 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Trigger Mode PTT PTT PTT
Page Ducking -20 dB -20 dB -20 dB -50 dB ~ 0 dB
Direct Input Volume 0 dB 0 dB 0 dB -40 dB ~ +10 dB
Bass 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Treble 0 dB 0 dB 0 dB -6 dB ~ +6 dB
Miscellaneous Master Volume Linked N
Output 1 *Out 1/2 Input Sel (Stereo 0nly)
Out 1 Input Sel (Dual Mono only) 1
Input Mix - Input 1 (Mixer only) Y
Input Mix - Input 2 (Mixer only) N
Input Mix - Input 3 (Mixer only) N
Input Mix - Input 4 (Mixer only) N
Spkr EQ Preset 01 80 Hz HPF 01 80 Hz HPF 01 80 Hz HPF
Dynamic EQ Enable N N N
Page Enable N N N
Page Level 0 dB 0 dB 0 dB -20 dB ~ +20 dB
Output 2 *Out 1/2 Input Sel (Stereo 0nly) *1/2 (2)
Out 1 Input Sel (Dual Mono only) 3
Input Mix - Input 1 (Mixer only) Y
Input Mix - Input 2 (Mixer only) N
Input Mix - Input 3 (Mixer only) N
Input Mix - Input 4 (Mixer only) N
Spkr EQ Preset 01 80 Hz HPF 01 80 Hz HPF 01 80 Hz HPF
Dynamic EQ Enable N N N
Page Enable N N N
Page Level 0 dB 0 dB 0 dB -20 dB ~ +20 dB
Auxout Auxout Input Sel (Stereo/Dual Mono) 1+2 sum 1 Fixed
Auxout Input Mix - Input 1 (Mixer only) Y
Auxout Input Mix - Input 2 (Mixer only) N
Auxout Input Mix - Input 3 (Mixer only) N
Auxout Input Mix - Input 4 (Mixer only) N
Spkr EQ Preset 01 80 Hz HPF 01 80 Hz HPF 01 80 Hz HPF
Dynamic EQ Enable N N N
Page Enable N N N
Page Level 0 dB 0 dB 0 dB -20 dB ~ +20 dB
*These parameters are linked and displayed on the same menu screen. The numbers in parenthesis indicate which input is
automatically selected and routed to the respective output.
