2.0 Designing with the E-4 System
When mounting sensing microphones, always maintain a dis-
tance of 6 feet (1.8 m) minimum between the microphone and the
speaker.
Mic
≥ 6'
≥ 6'
Mic
Mic
≥ 6'
≥ 6'
Ceiling Flush
Wall Surface
Ceiling Surface
Sensing
microphone
≥6 ft
(1.8 m)
Sensing
microphone
Sensing
microphone
≥6 ft
(1.8 m)
≥6 ft
(1.8 m)
≥6 ft
(1.8 m)
≥6 ft
(1.8 m)
≥6 ft
(1.8 m)
