Bose FreeSpace IZA 2120-HZ Service Manual

100
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
ZA 2120-LZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C430 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C431 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C432 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C433 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C434 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C435 CC, 50V, 0.01U, 5%, 0603 150F-103J+P-AC
C439 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C440 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C700 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C701 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C702 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C703 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C704 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C705 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C706 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C707 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C708 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C709 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C710 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C711 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C712 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C713 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C714 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C715 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C716 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C717 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C718 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C719 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C720 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C721 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C722 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C723 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C724 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C725 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C726 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C727 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C728 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C729 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C730 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C731 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C732 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C733 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C734 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C735 CC, 50V, 0.01U, 5%, 0603 150F-103J+P-AC
C736 CC, 50V, 0.01U, 5%, 0603 150F-103J+P-AC
C739 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C740 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C741 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C742 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C743 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C744 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C745 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
