Bose FreeSpace IZA 2120-HZ Service Manual

99
ELECTRICAL PART LIST
FreeSpace
®
ZA 2120-LZ Rear Panel PCB Assembly
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
R774 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R776 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R777 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R778 RMG, 1/16W, 20K, 1%, 0603/1608 4723-203A+P
R779 RMG, 1/16W, 20K, 1%, 0603/1608 4723-203A+P
R780 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R781 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R782 RMG, 1/16W, 200K, 1%, 0603/1608 4723-204A+P
R783 RMG, 1/16W, 200K, 1%, 0603/1608 4723-204A+P
R786 RMG, 1/16W, 270K, 1%, 0603 4723-274A+P
R787 RMG, 1/16W, 270K, 1%, 0603 4723-274A+P
R788 RMG, 1/16W, 3.9K, 1%, 0603/1608 4723-392A+P
R789 RMG, 1/16W, 3.9K, 1%, 0603/1608 4723-392A+P
R790 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R791 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R792 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R793 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R794 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R795 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R796 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R797 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R798 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R799 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R804 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R805 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R806 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R807 RMG, 1/16W, 100K, 1%, 0603 4723-104A+P-R
R808 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R809 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R810 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R811 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
Capacitors
Reference
Designator
Description
V
endor Part
Number
Note
C402 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C404 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C406 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C408 CC, 50V, 0.01U, 5%, 0603 150F-103J+P-AC
C409 CE, 25V, 10U, 20%, 5.3X5.4, SMD,
UWX1E100MCR1GB, NCC
157E-106M+3-JJC
C411 CE, 25V, 10U, 20%, 5.3X5.4, SMD,
UWX1E100MCR1GB, NCC
157E-106M+3-JJC
C414 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C415 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C417 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C419 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C420 CE, 25V, 100UF, 20%, 6.3X7.7, SMD 157E-107M+3-LO
C421 CE, 25V, 100UF, 20%, 6.3X7.7, SMD 157E-107M+3-LO
C425 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C426 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C427 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
