Bose FreeSpace IZA 2120-HZ Service Manual

113
1.10 Verify that the output level is 120W from both channels and that the THD+N is
<0.3%.
2. Frequency Response and Output Noise Tests
2.1 Set the front panel Input A / Input B switch to Input A. Apply a -30dBV, 1kHZ sine wave to the
input A RCA jacks. Adjust the Input A gain rear panel control to allow a 1W output level.
Reference the dB meter to this output level.
2.2 Change the input frequency to 55Hz. Verify that the output level is -3dBr +/- 1.
2.3 Change the input frequency to 18kHz. Verify that the output level is -2dBr +/- 1.
2.4 Turn off the signal generator output. Measure the noise level with a 20kHZ filter and
A-weighting. Verify that it is < -51dBV.
2.5 Repeat steps 2.1 to 2.4 for Input B.
2.6 Set the front panel Input A / Input B switch to Input A. Apply a -30dBV, 1kHZ sine wave to the
input A Euro block jacks. Adjust the Input A gain rear panel control to allow a 1W output level.
Reference the dB meter to this output level.
2.7 Change the input frequency to 55Hz. Verify that the output level is -3dBr +/- 1.
2.8 Change the input frequency to 18kHz. Verify that the output level is -2dBr +/- 1.
2.9 Turn off the signal generator output. Measure the noise level with a 20kHZ filter and
A-weighting. Verify that it is < -51dBV.
2.10 Repeat steps 2.6 to 2.9 for Input B.
2.11 Apply a -30dBV, 1kHZ sine wave to the Page Input jack. Adjust the Page Input gain rear
panel control to allow a 1W output level. Reference the dB meter to this output level.
2.12 Change the input frequency to 55Hz. Verify that the output level is -5dBr +/- 1.
2.13 Change the input frequency to 18kHz. Verify that the output level is -3.5dBr +/- 1.
2.14 Turn off the signal generator output. Measure the noise level with a 20kHZ filter and
A-weighting. Verify that it is < -48dBV.
2.15 Apply a -30dBV, 1kHZ sine wave to the Aux Input jack located on the front panel.
Reference the dB meter to this output level.
2.16 Change the input frequency to 55Hz. Verify that the output level is -3dBr +/- 1.
2.17 Change the input frequency to 18kHz. Verify that the output level is -2dBr +/- 1.
2.18 Turn off the signal generator output. Measure the noise level with a 20kHZ filter and
A-weighting. Verify that it is < -51dBV.
TEST PROCEDURES

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
