Bose FreeSpace IZA 2120-HZ Service Manual

13
Product Information
FreeSpace
®
IZA 2120-LZ
Product Description
For background/foreground music and paging applications, Bose
®
FreeSpace
®
audio
experience when using FreeSpace
®
loudspeakers. Optimized for
Loudspeaker EQ to enrich audio quality, Opti-voice
®
paging for clear
speech intelligibility while providing seamless transitions and Dynamic
EQ that ensures full and balanced music at any volume level.
Key Features
• Opti-voice
®
paging equalizes the vocal frequency range for clear
speech intelligibility while providing seamless transitions.
• Dynamic EQ ensures full and balanced music at any volume level.
• Loudspeaker EQ
to Bose
®
loudspeakers: FreeSpace® DS 16, DS 40, DS 100 and
RoomMatch
®
Utility RMU105.
• Remote option for volume/source selection eliminates the need for
• Expansion-ready connectivity
additional zones.
•
optimized for
low-impedance applications.
• Intuitive feature setup
a PC for output, remote, paging, auxiliary input/output and automatic
standby options.
• Auto-Standby feature
when not in use.
•
provides end users with tone,
source selection and master volume controls as well as a connection
to mobile sources via a 3.5 mm connector.
• Remote muting
control system.
Applications
• Designed for a wide range of applications,
including:
• Retail stores
• Restaurants and bars
• Hospitality venues
• Conference centers
• Schools
• Auxiliary zones

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
