Bose FreeSpace IZA 2120-HZ Service Manual

47
ELECTRICAL PART LIST
Resistors
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R400 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R401 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R402 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R403 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R404 RMG, 1/16W, 30.9K, 1%, 0603/1608 4723-3092
R405 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R407 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R408 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R409 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R410 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R411 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R412 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R413 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R414 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A
R415 RMG, 1/16W, 33R, 1%, 0603 4723-330A
R416 RMG, 1/16W, 33R, 1%, 0603 4723-330A
R417 RMG, 1/16W, 33R, 1%, 0603 4723-330A
R418 RMG, 1/16W, 33R, 1%, 0603 4723-330A
R419 RMG, 1/16W, 5.1K, 1%, 0603/1608 4723-512A
R420 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761
R421 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761
R422 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761
R423 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761
R424 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761
R425 RMG, 1/16W, 9.76K, 1%, 0603 4723-9761
R426 RMG, 1/16W, 715R, 1%, 0603 4723-7150
R427 RMG, 1/16W, 715R, 1%, 0603 4723-7150
R428 RMG, 1/16W, 8.2K, 1%, 0603/1608 4723-822A
R429 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R430 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R431 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R432 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R433 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R434 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R435 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R436 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R437 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R438 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R439 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R440 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R441 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R442 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R443 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R444 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R454 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R456 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R457 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R458 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R460 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R462 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R463 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R467 RMG, 1/16W, 0R, 1%, 0603 4723-000A

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
