Bose FreeSpace IZA 2120-HZ Service Manual

48
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
R469 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R470 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R471 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R472 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R473 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R479 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R480 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R481 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R482 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R483 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R484 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R485 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R486 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R487 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R488 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R489 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R490 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R491 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R492 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R493 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R494 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R495 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R496 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R497 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R498 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R499 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R500 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R501 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R502 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R503 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R504 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R505 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R506 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R509 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R510 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R511 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R512 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R513 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R514 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R515 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R516 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R517 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R518 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R519 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R520 RCFA, 1/16W, 47RX4, 5%, 0603 4703-470J04
R522 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R529 RMG, 1/16W, 47R, 1%, 0603 4723-470A
R530 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A
R531 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R533 RMG, 1/16W, 200K, 1%, 0603/1608 4723-222A
R534 RMG, 1/16W, 200K, 1%, 0603/1608 4723-222A
R535 RMG, 1/16W, 200K, 1%, 0603/1608 4723-222A
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
