Bose FreeSpace IZA 2120-HZ Service Manual

49
ELECTRICAL PART LIST
Resistors (continued)
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R536 RMG, 1/16W, 200K, 1%, 0603/1608 4723-222A
R537 RMG, 1/16W, 22K, 1%, 0603 4723-223AR
R549 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R550 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R551 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R552 RMG, 1/16W, 0R, 1%, 0603 4723-000A
R553 RMG, 1/16W, 392R, 1%, 0603 4723-3920
R554 RMG, 1/16W, 392R, 1%, 0603 4723-3920
R555 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R556 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R557 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R558 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R559 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R561 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R565 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R568 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R569 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R572 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R573 RMG, 1/10W, 13.7K, 1%, 0603 4720-1372
R574 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R575 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R576 RMG, 1/10W, 13.7K, 1%, 0603 4720-1372
R577 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R578 RMG, 1/10W, 13.7K, 1%, 0603 4720-1372
R579 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R580 RMG, 1/10W, 13.7K, 1%, 0603 4720-1372
R581 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R582 RMG, 1/10W, 20K, 1%, 0603 4720-203A
R583 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R584 RMG, 1/10W, 20K, 1%, 0603 4720-203A
R585 RMG, 1/10W, 20K, 1%, 0603 4720-203A
R586 RMG, 1/10W, 20K, 1%, 0603 4720-203A
R587 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R588 RMG, 1/16W, 13K, 1%, 0603 4723-133AR
R589 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R590 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R591 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R592 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R597 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R598 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R599 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R600 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R601 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R602 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R603 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R604 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R605 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R606 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R607 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R608 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R609 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R610 RMG, 1/16W, 100R, 1%, 0603 4723-101A

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
