Bose FreeSpace IZA 2120-HZ Service Manual

51
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C428 CC, 50V, 33PF, 5%, 0603, C0G 150F-330JAC
C430 CC, 6.3V, 4.7U, 10%, 0603 150B-475KAC
C431 CC, 6.3V, 4.7U, 10%, 0603 150B-475KAC
C432 CC, 6.3V, 4.7U, 10%, 0603 150B-475KAC
C433 CC, 6.3V, 4.7U, 10%, 0603 150B-475KAC
C434 CC, 6.3V, 4.7U, 10%, 0603 150B-475KAC
C435 CC, 50V, 2700PF, 10%, 0603 150F-272KAC
C436 CC, 50V, 270P, 10%, 0603, 1x2 150F-271KAC
C437 CC, 50V, 270P, 10%, 0603, 1x2 150F-271KAC
C438 CC, 50V, 270P, 10%, 0603, 1x2 150F-271KAC
C439 CC, 50V, 270P, 10%, 0603, 1x2 150F-271KAC
C440 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C441 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C442 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C443 CC, 50V, 220PF, 5%, 0603, C0G 150F-221JAC
C444 CT, 6.3V, 100uF, 20%, SMD, 3.5X2.8MM 154B-107MFE
C445 CE, 35V, 47U, 20%, SM, 6.6X5.7, LOW, ESR,
LELON
157Q-476MMKR5
C446 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C447 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C448 CE, 35V, 47U, 20%, SM, 6.6X5.7, LOW, ESR,
LELON
157Q-476MMKR5
C449 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C450 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C451 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C452 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C453 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C454 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C455 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C456 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C457 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C458 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C461 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C462 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C463 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C464 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C465 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C466 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C467 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C468 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106MEJ
C469 CC, 50V, 22P, 5%, 0603, C0G 150F-220JAC
C470 CC, 50V, 22P, 5%, 0603, C0G 150F-220JAC
C471 CC, 50V, 22P, 5%, 0603, C0G 150F-220JAC
C472 CC, 50V, 22P, 5%, 0603, C0G 150F-220JAC
C473 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C474 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C475 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C476 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C477 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C479 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C481 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C482 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
