Bose FreeSpace IZA 2120-HZ Service Manual

52
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C483 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C484 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C485 CC, 50V, 100PF, 5%, 0603, C0G 150F-101JAC
C486 CE, 25V, 220U, 20%, SM, 8.4X10, LOW, ESR,
LELON
157E-227MPSR5
C487 CE, 25V, 100UF, 20%, 6.3X7.7, SMD 157E-107MLO
C488 CE, 25V, 100UF, 20%, 6.3X7.7, SMD 157E-107MLO
C489 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C490 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C491 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C492 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C493 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C494 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C495 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C496 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C497 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C498 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C499 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C500 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C503 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C504 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C505 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C511 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C512 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C513 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C514 CC, 50V, 1000P, 5%, 0603, X7R 150F-102JAC
C515 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C516 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C517 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C518 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C519 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C520 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C521 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C522 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C523 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C524 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C525 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C526 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C527 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C528 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C529 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C530 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C531 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C534 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C535 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C536 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C537 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C538 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C539 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C540 CC, 50V, 560P, 10%, 0603/1608, 1X2 150F-561KAC
C541 CC, 50V, 560P, 10%, 0603/1608, 1X2 150F-561KAC
C542 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
