Bose FreeSpace IZA 2120-HZ Service Manual

53
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace
®
IZA 2120-HZ DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C543 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C544 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C545 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C546 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C547 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C548 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C549 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C550 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C551 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C552 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C553 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C554 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C555 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C556 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C557 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C558 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C559 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C560 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C561 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C562 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C563 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104KAC
C564 CE, 25V, 10U, 20%, 5.3X5.4, SMD,
UWX1E100MCR1GB, NCC
157E-106MJJC
C565 CE, 35V, 47U, 20%, SM, 6.6X5.7, LOW, ESR,
LELON
157Q-476MMKR5
Inductors
Reference
Designator
Description
V
endor Part
Number
Note
L400 INDUCTOR, 22UH, 20%, 8.1X8, B1000AS-
220M=P3, SMD, TOKO
1803-0103
L401 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L404 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L405 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L407 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L408 FERRITE, BEAD, CHIP, SEBW201209U121MT,
0805
1808-0872
L409 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L410 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L411 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L412 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L415 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878
L416 FERRITE, CHIP, 0603, BLM18AG102SN1D,
MURATA
1808-0878

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
