Bose FreeSpace IZA 2120-HZ Service Manual

61
Capacitors (continued)
ELECTRICAL PART LIST
FreeSpace IZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C773 CC, 50V, 22P, 5%, 0603, C0G 150F-220J+P-AC
C774 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C775 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C776 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C777 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C778 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C779 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C780 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C785 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C786 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C788 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C789 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C790 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C795 CE, 6.3V, 220U, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU
C796 CE, 6.3V, 220U, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU
C797 CE, 6.3V, 220U, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU
C798 CE, 6.3V, 220U, 20%, SM, 6.3X5.3, NOVER 157B-227M+3-LJU
C800 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C802 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C804 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C805 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C810 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C814 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C815 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C816 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C817 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C818 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C821 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C822 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C823 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C824 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C825 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C826 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C827 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C828 CE, 16V, 10U, 20%, SM, 3X5.4, 85C-2000H 157D-106M+3-EJ
C833 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C834 CC, 50V, 100PF, 5%, 0603, C0G 150F-101J+P-AC
C835 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C836 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C837 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C840 CC, 50V, 470PF, 5%, 0603, C0G 150F-471J+P-AC
C841 CC, 50V, 470PF, 5%, 0603, C0G 150F-471J+P-AC
C844 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C845 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C846 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C847 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C848 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C849 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C850 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C851 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C852 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD
C853 CC, 100V, 0.1U, 10%, 1206, AVX 150H-104K+6-CFD

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
