Bose FreeSpace IZA 2120-HZ Service Manual

62
ELECTRICAL PART LIST
Capacitors (continued)
FreeSpace IZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C854 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C855 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C856 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C857 CC, 50V, 1000p, 5%, 0805, 1.25X2.0, MURATA 150F-103K+P-AC
C860 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C861 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C862 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C863 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C864 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C865 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C866 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C867 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C868 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C869 CC, 50V, 0.1uF, 10%, 0603, X7R 150F-104K+P-AC
C870 CC, 50V, 0.01U, 5%, 0603 150F-103J+P-AC
Diodes
Reference
Designator
Description
V
endor Part
Number
Note
D704 DIODE, BAV99, SOT23 4840-8970+3
D705 DIODE, BAV99, SOT23 4840-8970+3
D706 DIODE, BAV99, SOT23 4840-8970+3
D707 DIODE, BAV99, SOT23 4840-8970+3
D710 DIODE, BAV99, SOT23 4840-8970+3
D711 DIODE, BAV99, SOT23 4840-8970+3
D712 DIODE, BAV99, SOT23 4840-8970+3
D713 DIODE, BAV99, SOT23 4840-8970+3
D714 DIODE, BAV99, SOT23 4840-8970+3
D715 DIODE, BAV99, SOT23 4840-8970+3
D716 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY,
SMD
480T-54S0+3
Z700 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-
116.2B)
4837-6V21+3
Z701 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-
116.2B)
4837-6V21+3
Z702 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-
116.2B)
4837-6V21+3
Z703 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM(RLZTE-
116.2B)
4837-6V21+3
Reference
Designator
Description
V
endor Part
Number
Note
Q708 TR, MMBT4403LT1G, SMD 4854-4030+3
Q709 TR, MMBT4403LT1G, SMD 4854-4030+3
Q710 TR, MMBT4403LT1G, SMD 4854-4030+3
Q711 TR, MMBT4403LT1G, SMD 4854-4030+3
Q712 TR, MMBT4403LT1G, SMD 4854-4030+3
Q713 TR, MMBT4403LT1G, SMD 4854-4030+3
Q714 TR, MMBT4403LT1G, SMD 4854-4030+3
Q715 TR, MMBT4403LT1G, SMD 4854-4030+3
Q719 TR, NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010+3
Q720 TR, NPN, MMBT4401, SOT-23, HFE:, 20-300, SM 4854-4010+3
Transistors

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
