Bose FreeSpace IZA 2120-HZ Service Manual

64
ELECTRICAL PART LIST
Resistors
FreeSpace
®
ZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endo
r
Part
Number
Note
R402 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A+P
R403 RMF, 1/4W, 2R2, 1%, 1206 4715-2R2A+6
R404 RMG, 1/16W, 8.2K, 1% 4723-822A+P
R405 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R406 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R407 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R408 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R409 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R410 RMG, 1/16W, 820R, 1%, 0603 4723-821A+P-R
R411 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R412 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R413 RMG, 1/16W, 200K, 1%, 0603/1608 4723-221A+P
R414 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R415 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R416 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R417 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R418 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R419 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R420 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R421 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R422 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R423 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R424 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R425 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
R428 RMG, 1/16W, 22K, 1%, 0603 4723-223A+P-R
R429 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R430 RMF, 1/4W, 2R2, 1%, 1206 4715-2R2A+6
R431 RMG, 1/16W, 5.1K, 5%, 0603/1608 4723-512J+P
R432 RMG, 1/16W, 5.1K, 5%, 0603/1608 4723-512J+P
R433 RMG, 1/16W, 5.1K, 5% 4723-512J+P
R436 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R437 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R438 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R441 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R442 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R443 RMG, 1/16W, 200K, 1%, 0603/1608 4723-222A+P
R444 RMG, 1/16W, 200K, 1%, 0603/1608 4723-222A+P
R445 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R447 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R448 RMG, 1/16W, 22K, 1%, 0603 4723-223A+P-R
R700 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R701 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R702 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A+P
R703 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A+P
R704 RMG, 1/16W, 3.3K, 1%, 0603 4723-332A+P-R
R705 RMG, 1/10W, 4.7M, 1%, 0603 4720-475A+P
R706 RMG, 1/10W, 4.7M, 1%, 0603 4720-475A+P
R707 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A+P
R708 RMG, 1/16W, 4.7K, 1%, 0603/1608 4723-472A+P
R709 RMG, 1/16W, 270R, 1%, 0603 4723-271A+P-R
R710 RMG, 1/16W, 270R, 1%, 0603 4723-271A+P-R

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
