Bose FreeSpace IZA 2120-HZ Service Manual

65
ELECTRICAL PART LIST
Resistors (continued)
FreeSpace
®
ZA 2120-HZ Rear Panel PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R711 RMG, 1/16W, 270R, 1%, 0603 4723-271A+P-R
R712 RMG, 1/16W, 270R, 1%, 0603 4723-271A+P-R
R713 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R714 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R715 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R716 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R717 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R718 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R719 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R720 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R721 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R722 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R723 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R724 RMG, 1/16W, 470R, 1%, 0603 4723-471A+P-R
R725 RMG, 1/16W, 560K, 1%, 0603/1608 4723-564A+P
R726 RMG, 1/16W, 560K, 1%, 0603/1608 4723-564A+P
R727 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R728 RMG, 1/16W, 47K, 1%, 0603 4723-473A+P-R
R729 RMG, 1/16W, 200K, 1%, 0603/1608 4723-204A+P
R730 RMG, 1/16W, 200K, 1%, 0603/1608 4723-204A+P
R731 RMG, 1/16W, 82K, 5%, 0603/1608 4723-823J+P
R732 RMG, 1/16W, 51K, 1%, 0603/16 4723-513A+P
R733 RMG, 1/16W, 82K, 5%, 0603/1608 4723-823J+P
R734 RMG, 1/16W, 51K, 1%, 0603/16 4723-513A+P
R739 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R740 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R741 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R742 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R743 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R744 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R745 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R746 RMG, 1/16W, 1K, 1%0603/1608 4723-102A+P
R747 RMG, 1/16W, 36K, 1%, 0603 4723-363A+P
R748 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R749 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R751 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R752 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R753 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R754 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R755 RMG, 1/16W, 36K, 1%, 0603 4723-363A+P
R756 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R757 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R758 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R759 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R762 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R765 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R767 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R768 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R769 RMG, 1/16W, 10K, 1%, 0603 4723-103A+P-R
R771 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P
R772 RMG, 1/16W, 100R, 1%, 0603 4723-101A+P

Bose FreeSpace IZA 2120-HZ Specifications

General

Maximum current	5 A
AC input voltage	230 V
AC input frequency	50 Hz
Amplifier class	D
Frequency range	55 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	- W
Total Harmonic Distortion (THD)	0.3 %
Purpose	Performance/stage
Equalizer	Yes
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
Line inputs (RCA)	2
Speakers connectivity type	RCA
Package weight	5400 g

Weight and Dimensions

Depth	324 mm
Width	483 mm
Height	44 mm
Weight	4100 g
