Bose PowerMatch PM8250 Service Manual

17
PACKAGING PART LIST
PowerMatch
®
Amplifier (refer to Figure 1)
Figure 1. PowerMatch Amplifier Packing View
1
2
3
4
5
6
Item
Number
Description Part Numbe
r
Qty. Note
1 PACKING, FOAM, PE, F, TOP ASSY 343459-0010 1
2
PACKING, FOAM, PE, F, BOTTOM REAR 343458-0010 1
3 PACKING, FOAM, PE, BOTTOM, FRT 343457-0010 1
4 CARTON, RSC, 26X21.38X7.75, DW, K 343456-0010 1
5
BAG, FILM, PE 24.00 X 30.00 X 3MIL 344095-0010 1
6 GUIDE, SETUP, CONFIG PRO AMP 344846-0010 1
-
A
C LINE CORD, US/CAN, PM8500(N) ONLY 330379-0010 1 3
A
C LINE CORD, EURO, PM8500
(
N
)
ONLY 343537-0010
A
C LINE CORD, JAPAN, PM8500
(
N
)
ONLY 343538-0010
A
C LINE CORD, UK, PM8500(N) O NL
Y
343539-0010
A
C LINE CORD,
A
US, PM8500
(
N
)
ONLY 343540-0010
AC LINE CORD, CHINA, PM8500(N) ONLY 345431-0010
- AC LINE CORD, IEC C13, US/CAN 363478-0010 3
A
C LINE CORD, IEC C13, EURO 363477-0010
A
C LINE CORD, IEC C13, JAPAN 363475-0010
AC LINE CORD, IEC C13, UK 363476-0010
A
C LINE CORD, IEC C13, AUS 363474-0010
- KIT, ACCESSORY, CONNECTOR, 8 CH
A
NNEL AMPS 343511-0010 1 3
KIT, ACCESSORY, CONNECTOR, 4 CHANNEL AMPS 343511-0020 1
- FERRITE KIT, ETHERNET CABLE (4 CH AMPS ONLY) 374156-0010 1

