MAIN PART LIST
PowerShare PS404A and PS604A (see Figure 2)
Item
Number
Description Part Number Qty. Note
1 INSULATOR, PC BOARD (USED ON TOP COVER) 748404-001S 1 3
2 ASSY, TOP COVER, SVCE (INCLUDES PC SHEET, ITEM 1) 748388-011S 1
3 SCREW, TOP COVER - 12
4
FOAM, FAN
- 0.3
5 BRACKET, FAN - 2
6 SCREW, FAN BRACKET - 8
7 SCREW, FAN MOUNTING - 8
8 FAN, DC, 5V, 6000RPM (INCLUDES BRACKET, ITEM 5) 748033-001S 2 3
9 SHEET, INSULATING, SMPS - 1
10 SCREW, PCB AND FRONT GROUND - 1
11 BRACKET, GND, LED PCB - 1
12 SCREW, AC POWER SWITCH - 2
13 SWITCH, AC POWER ON-OFF 748030-0010 1 3
14 SCREW, FRONT BEZEL - 4
15 PUSH KNOB 748029-0110 1
16 BEZEL, PLASTIC, FRONT, SVCE 747903-013S 1
17 LIGHTPIPE, FRONT LED PCB - 9
18 PCB ASSY, LED, PS604A/404A, SVCE 807692-001S 1 1
19 PANEL, FRONT, AMP, PS404A, SVCE 795641-011S 1
PANEL, FRONT, AMP, PS604A, SVCE 795641-012S
20 SCREW, FRONT PANEL - 3
21 AIR BAFFLE, CHASSIS, ONE PIECE 776140-0010 1 3
22 SCREW, AMP PCB HEATSINK (BOTTOM OF UNIT) - 4
23 RACK EAR, FRONT, SVCE 748545-011S 2
24 SCREW, RACK EAR - 6
25 PCB ASSY, AMPLIFIER 732946-0010 1 1
26 CHASSIS - 1
27 SCREW, REAR MOUNTING EAR - 6
28 BRACKET, REAR, SVCE 747855-011S 2
29 TUBE, SPACER, 14MM - 3
30 PCB ASSY, DSP, PS404A/PS604A, SVCE 797164-001S 1 1
31 SCREW, DSP/AMPLINK/AMP - 13
32 SCREW, AMPLINK PCB - 2
33 PCB ASSY, AMPLINK, PS404A, SVCE 797166-001S 1 1
PCB ASSY, AMPLINK, PS604A, SVCE 797166-002S
34 TOOTH WASHER FOR GND - 2
35 NUT, GND - 2

Bose PowerShare PS404A Specifications

General

Purpose	-
On/off switch	Yes
Product color	Black
Connectivity technology	Wired
Audio output channels	4.0 channels
Peak power per channel	400 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.04 %
Ethernet LAN (RJ-45) ports	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14 W

Weight and Dimensions

Depth	414 mm
Width	483 mm
Height	44 mm
Weight	6400 g
