TEST PROCEDURE
Hi-Pot Test
THIS IS A MANDATORY TEST
Note: If the unit under test requires disassembly as part of the repair, it MUST be Hi-Pot
tested before being returned to the customer to ensure that there is no potential shock hazard.
This test requires a Hi-Pot tester with a ground bond attachment to perform this test.
Connections:
The Hi-Pot tester connects to the unit under test (UUT) by means of a wiring harness. The
AC line cord of the UUT plugs into the Hi-Pot tester AC adapter box. The return line connects to
all output connectors.
Hi-Pot Tester Settings:
AC Input to Earthed Parts
All units - 1500 VAC, rise time = 1 sec., dwell = 3 seconds, current limit = 5.0 mA
• Connect the AC mains cord to loudspeaker under test. Plug the other end of the AC cord
into the Hi-Pot tester AC adapter box. The AC adapter box connects to the High Voltage (HV)
connection on the Hi-Pot tester.
• Connect the Hi-Pot tester RETURN line to a ground point on the chassis.
• With the tester set to the above parameters, perform the test. If the unit fails, troubleshoot it
and repair the problem. If it passes this portion of the test, proceed to the below test.
Ground Bond Test
Note: This test only needs to be performed if the chassis ground wire from the AC IEC
connector to the inside of the chassis of the unit has been removed or disturbed as part of a
repair. If it has not, this test does not need to be performed. This test measures current handling
capability between the ground blade on the AC inlet or mains plug and the earth bond point on
the chassis of the unit.
Ground Bond Tester Settings:
10A, < 12VAC open circuit, < 0.1 Ohms from AC earth terminal on IEC connector in chassis, to
earth bond point on rear of chassis. Test duration = 4 seconds.
• Connect the AC mains cord to the back of the amplier under test. Plug the other end of
the AC cord into the ground bond test box.
• With the tester set to the above parameters, perform the test. If the unit fails, remove the top
cover and repair the problem. Once the unit is repaired, repeat the Hi-Pot and the ground
bond tests to ensure the unit is safe to return to the customer.

Bose PowerShare PS404A Specifications

General

Purpose	-
On/off switch	Yes
Product color	Black
Connectivity technology	Wired
Audio output channels	4.0 channels
Peak power per channel	400 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.04 %
Ethernet LAN (RJ-45) ports	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14 W

Weight and Dimensions

Depth	414 mm
Width	483 mm
Height	44 mm
Weight	6400 g
