Bose PowerShare PS404A User Manual

14
Resistors (continued)
ELECTRICAL PART LIST
Amplier PCB Assembly
Reference
Designator
Description Part Number Note
R142 0603, .1W, 1%, 7.15K 191465-7151
R143 0603, .1W, 1%, 7.15K 191465-7151
R144 0603, .1W, 1%, 200K 191465-2003
R145 0603, .1W, 1%, 200K 191465-2003
R146 0805, .125W, 1%, 100K 133625-1003
R147 0805, .125W, 1%, 100K 133625-1003
R148 0603, .1W, 1%, 1K 191465-1001
R149 0603, .1W, 1%, 10K 191465-1002
R200 0805, .125W, 1%, 49.9K 133625-4993
R201 0603, .1W, 1%, 1K 191465-1001
R202 0603, .1W, 1%, 1K 191465-1001
R203 0805, .125W, 1%, 49.9K 133625-4993
R204 0603, .1W, 1%, 1K 191465-1001
R205 0603, .1W, 1%, 3.09K 191465-3091
R206 0603, .1W, 1%, 1K 191465-1001
R207 0805, .125W, 1%, 49.9K 133625-4993
R208 0805, .125W, 1%, 49.9K 133625-4993
R209 0603, .1W, 1%, 3.09K 191465-3091
R210 0603, .1W, 1%, 3.09K 191465-3091
R211 0603, .1W, 1%, 3.09K 191465-3091
R212 0603, .1W, 1%, 2.15K OHM 191465-2151
R213 0603, .1W, 1%, 2.15K OHM 191465-2151
R214 0603, .1W, 1%, 14.7K 191465-1472
R215 0603, .1W, 1%, 14.7K 191465-1472
R216 0603, .1W, 1%, 14.7K 191465-1472
R217 0603, .1W, 1%, 14.7K 191465-1472
R218 0603, .1W, 1%, 30.1K 191465-3012
R219 0603, .1W, 1%, 30.1K 191465-3012
R220 0603, 0.1W, 1%, 1.30K 191465-1301
R221 0603, 0.1W, 1%, 1.30K 191465-1301
R222 0603, 0.1W, 1%, 1.30K 191465-1301
R223 0603, .1W, 1%, 24.9 OHM 191465-24R9
R224 0603, .1W, 1%, 24.9 OHM 191465-24R9
R225 0603, 0.1W, 1%, 1.30K 191465-1301
R226 0603, .1W, 1%, 30.1K 191465-3012
R227 0603, .1W, 1%, 30.1K 191465-3012
R228 0603, .1W, 1%, 2.0K 191465-2001
R229 0603, .1W, 1%, 2.0K 191465-2001
R230 0603, 0.1W, 1%, 374 OHMS 191465-3740
R231 0603, 0.1W, 1%, 374 OHMS 191465-3740
R232 0603, 0.1W, 1%, 976 OHMS 191465-9760
R233 0603, .1W, 1%, 1K 191465-1001

Bose PowerShare PS404A Specifications

General

Purpose	-
On/off switch	Yes
Product color	Black
Connectivity technology	Wired
Audio output channels	4.0 channels
Peak power per channel	400 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.04 %
Ethernet LAN (RJ-45) ports	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14 W

Weight and Dimensions

Depth	414 mm
Width	483 mm
Height	44 mm
Weight	6400 g
