21
Resistors (continued)
ELECTRICAL PART LIST
Amplier PCB Assembly
Reference
Designator
Description Part Number Note
R2133 0603, 100MW, 1%, 1.33K 191465-1331
R2134 0603, 100MW, 1%, 1.33K 191465-1331
R2135 0603, .1W, 1%, 49.9K 191465-4992
Capacitors
Reference
Designator
Description Part Number Note
C100 1206, X7R, 25V, 10%, 4.7uF 262063-475
C101 1206, X7R, 25V, 10%, 4.7uF 262063-475
C102 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C103 0805, X7R, 50V, 0.1uF 133623-104
C104 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C105 0805, X7R, 50V, 0.1uF 133623-104
C106 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C107 0805, X7R, 50V, 0.1uF 133623-104
C108 C0G, 0603, 50V, 5%, 470pF 188454-471
C109 0805, X7R, 50V, 0.1uF 133623-104
C110 X7R, 1210, 25V, 10%, 22uF, COMM 759068-226K1E
C111 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C112 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C113 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C114 X7R, 0805, 6.3V, 10%, 10uF 359399-106K
C115 X7R, 0603, 16V, 10%, 1uF 257154-105K16
C116 0805, X7R, 50V, 0.1uF 133623-104
C117 C0G, 0603, 50V, 5%, 470pF 188454-471
C118 X7R, 0805, 6.3V, 10%, 10uF 359399-106K
C119 0805, X7R, 50V, 0.1uF 133623-104
C120 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C121 0805, X7R, 50V, 0.1uF 133623-104
C122 1206, X7R, 25V, 10%, 4.7uF 262063-475
C123 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C125 1206, X7R, 25V, 10%, 4.7uF 262063-475
C126 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C127 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C128 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C129 0805, X7R, 10%, 25V, 1UF 181264-105
C130 1206, X7R, 25V, 10%, 4.7uF 262063-475
C131 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C132 X7R, 0603, 10%, 0.1uF, 50V 191470-104
C133 0805, X7R, 10%, 25V, 1uF 181264-105
C134 C0G, 0603, 50V, 5%, 330pF 188454-331
C135 EL, 105C, 25V, 20%, 1000uF, 10mm DIA, CUT 196991-102E6P50
