Bose PowerShare PS404A - Page 28

28
Capacitors (continued)
ELECTRICAL PART LIST
Amplier PCB Assembly
Reference
Designator
Description Part Number Note
C495 X7R, 1210, 200V, 10%, 220nF 327916-224K
C496 X7R, 1210, 200V, 10%, 220nF 327916-224K
C497 X7R, 1210, 200V, 10%, 220nF 327916-224K
C498 C0G, 0603, 50V, 5%, 430pF 188454-431
Inductors
Reference
Designator
Description Part Number Note
L300 CORE, FERRITE, EQ20, LOW PROFILE 326426-0010
L301 INDUCTOR, BALANCED OUT, PQ26/25 753038-0010
L400 CORE, FERRITE, EQ20, LOW PROFILE 326426-0010
L401 INDUCTOR, BALANCED OUT, PQ26/25 753038-0010
T300 CORE, FERRITE, EQ20 326424-0010
T400 CORE, FERRITE, EQ20 326424-0010
Diodes
Reference
Designator
Description Part Number Note
D100 SCHTKY, SC70, 30V, SINGLE 268381-001
D101 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D102 SWITCHING, SOD123, 1N4148W 257662
D103 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D104 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D105 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D106 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D107 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D108 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D201 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D202 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D206 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D207 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
D208 SCHTKY, SC70, 30V, SINGLE 268381-001
D209 SCHTKY, SC70, 30V, SINGLE 268381-001
D300 SCHTKY, SC70, 30V, SINGLE 268381-001
D301 SCHTKY, SC70, 30V, SINGLE 268381-001
D302 SCHTKY, SC70, 30V, SINGLE 268381-001
D303 SCHTKY, SC70, 30V, SINGLE 268381-001
D304 SCHTKY, SC70, 30V, SINGLE 268381-001
D305 SCHTKY, SC70, 30V, SINGLE 268381-001
D306 SCHTKY, SC70, 30V, SINGLE 268381-001
D307 SCHTKY, SC70, 30V, SINGLE 268381-001
D308 SCHOTTKY, 1A, 30V, SOD123 317122-001
D309 SCHOTTKY, 1A, 30V, SOD123 317122-001
