30
Diodes (continued)
ELECTRICAL PART LIST
Amplier PCB Assembly
Reference
Designator
Description Part Number Note
D423 SCHOTTKY, 1A, 40V, SOD-123 329019-0010
D424 SW, 75V, 0.3A, SOT-323, BAV99W 298763-075
ZR100 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
ZR101 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
ZR200 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR201 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR202 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR203 ZENER, 5.6V, 250mW, 1%, SOT-23 135247-1232
ZR204 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR205 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR206 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR207 ZENER, 7.5V, 250mW, 1%, SOT-23 135247-1236
ZR300 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
ZR400 ZENER, 10.V, 225MW, 5%, SOT-23 135247-5240
Transistors
Reference
Designator
Description Part Number Note
Q100 BPLR, N, 40V, 200mA, SOT23 146819
Q101 BPLR, P, 40V, 200mA, SOT23 148596
Q102 BPLR, N, 40V, 200mA, SOT23 146819
Q103 BPLR, N, 40V, 200mA, SOT23 146819
Q104 BPLR, N, 40V, 200mA, SOT23 146819
Q105 BPLR, N, 40V, 200mA, SOT23 146819
Q106 BPLR, P, 40V, 200mA, SOT23 148596
Q204 BPLR, N, 40V, 200mA, SOT23 146819
Q205 BPLR, N, 40V, 200mA, SOT23 146819
Q300 BPLR, N, 40V, 200mA, SOT23 146819
Q301 BPLR, N, 40V, 200mA, SOT23 146819
Q302 BPLR, N, 40V, 200mA, SOT23 146819
Q303 BPLR, N, 40V, 200mA, SOT23 146819
Q304 BPLR, P, 40V, 200mA, SOT23 148596
Q305 BPLR, N, 40V, 200mA, SOT23 146819
Q306 BPLR, P, 40V, 200mA, SOT23 148596
Q307 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q308 NPN, LO SAT, 30V, 6A, SOT89 326375-0010
Q309 MFET, N-CH, 3.5A, 30V, SOT-23 362339-0010
Q310 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q311 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q312 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q313 NPN, LO SAT, 30V, 6A, SOT89 326375-0010
Q314 MFET, N-CH, 3.5A, 30V, SOT-23 362339-0010
