Bose PowerShare PS404A

37
Resistors (continued)
ELECTRICAL PART LIST
SMPS PCB Assembly
Reference
Designator
Description Vendor Part Number Note
R358 RMG, 1/10W, 4.02K, 1%, 0603 4720-4021
R359 RMG, 1/16W, 44.2K, 1%, 0603 4723-4422
R360 RMG, 1/10W, 4.02K, 1%, 0603 4720-4021
R361 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
R362 RMG, 1/16W, 1K, 1%, 0603/1608 4723-102A
R363 RMG, 1/8W, 4.7 OHMS, 1%, 1206 4721-4R7A
R367 RMG, 1/16W, 2K, 1%, 0603/1608 4723-202A
R368 RMG, 1/16W, 4.99K, 1%, 0603 4723-4991
R389 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R390 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R391 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R392 RMG, 1/16W, 2.2K, 1%, 0603/1608 4723-222A
R393 RMG, 1/16W, 3.3K, 1%, 0603 4723-332AR
R394 RMG, 1/16W, 1.5K, 1%, 0603 4723-152AR
R395 RMG, 1/16W, 510 OHMS, 1%, 0603 4723-511A
R398 RMG, 1/16W, 10K, 1%, 0603 4723-103AR
Capacitors
Reference
Designator
Description Vendor Part Number Note
C200 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C201 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C202 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C204 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C205 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C206 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C207 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C208 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C209 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C210 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C211 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C212 CC, 50V, 1000pF, 5%, 0603, X7R 150F-102JAC
C213 CC, 50V, 120pF, 5%, 0603, C0G 150F-121JAC
C214 CE, 50V, 10uF, 20%, RLT, 5X11, 105C, RX, NOVER 157F-106MIUTU
C215 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C216 CC, 25V, 10uF, 10%, 1206, 3.2X1.6, X5R 150E-106KCF
C218 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C219 CC, 50V, 0.01uF, 5%, 0603 150F-103JAC
C220 CE, 100V, 2000uF, 20%, RL, 35X25, SNAP-105C 157H-208M^&T
C221 CE, 100V, 2000uF, 20%, RL, 35X25, SNAP-105C 157H-208M^&T
C225 CC, 500V, 0.022uF, 10%, 1206 150L-223KCF
