Reference
Designator
Description Vendor Part Number Note
L=70 HEATSINK, SMPS, 14X30, L=70, AL-EXT, ANODIZE, BLACK 5401-0702
NTC200 THERMISTOR, NTC, 5R, 20%, 240V, 6A, 200C, RL, THINKING 5202-0045 3
Silicon PAD INSULATN-SHEET, SIL-PAD, 800, 55X22 3101-0961
T200 TRANS, PWR, 385V/80V, 600W, 4A, ER40 1806-4235 3
T201 CHOKE, COMMON, MODE, 10MH, MIN, 5A, SPACERS, 2.5MM,
AT
1805-0090 3
T202 CHOKE, COIL, 440UH, 15%, 17A, MI 1805-0570 3
T203 CHOKE, COMMON, MODE, 10MH, MIN, 5A, SPACERS, 2.5MM,
AT
1805-0090 3
T204 TRANS, PWR, 385V, 40W, ER28 1806-4236 3
T205 TRANS, CURRENT, 20A, EE8.3, SENSE 1806-4237
T206 TRANS, CURRENT, 20A, EE8.3, SENSE 1806-4237
Miscellaneous (continued)
ELECTRICAL PART LIST
SMPS PCB Assembly
