Bose PowerShare PS404A

47
Diodes (continued)
ELECTRICAL PART LIST
Rear Panel PCB Assembly
Reference
Designator
Description Vendor Part Number Note
Z842
DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM (RLZTE-116.2B
)
4837-6V21+3
Z843 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM (RLZTE-116.2B) 4837-6V21+3
Z844 DZ, 1/2W, 6.2VB, SMD, LL-34, ROHM (RLZTE-116.2B) 4837-6V21+3
Integrated Circuits
Reference
Designator
Description Vendor Part Number Note
U840 IC, CD74HC4067M96, MUX, SO24 3132-3021+0
U841 IC, SN74HC166DR, SHIFT, REG, 8BIT, PISO, 32NS, SO16 3132-3281+0
U842 IC, SN74HC166DR, SHIFT, REG, 8BIT, PISO, 32NS, SO16 3132-3281+0
U843 IC, SN74HC166DR, SHIFT, REG, 8BIT, PISO, 32NS, SO16 3132-3281+0
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
J840 SOCKET, M, 2P, P5, 300V, 15A, BLACK 2113-3361+1
J841B CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J842B CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J843B CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J844B CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J845B CONN, HEADER, 5P, P2.54, DIP, ST, M, L=11.08 2101-3409+0
J846B CONN, HEADER, 8P, P2.54, DIP, ST, M, L=8.54 2101-3408+0
J847B CONN, HEADER, 8P, P2.54, DIP, ST, M, L=8.54 2101-3408+0
J849 CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294+0
J850 CONNECTOR, PIN, HEADER, 4P, P2.54, ST, F 2101-3294+0
J851 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376+1
VR840 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E+0
VR841 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E+0
VR842 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E+0
VR843 VR, ROTARY, 20BKX1, 20%, V, L=15, 18TEETH, CTR 4751-226E+0
