74
Resistors (continued)
ELECTRICAL PART LIST
AmpLink PCB Assembly, PS604A Amplier
Reference
Designator
Description Vendor Part Number Note
R545 RMG, 1/16W, 33R, 1%, 0603 4723-330A+P
R546 RMG, 1/16W, 33R, 1%, 0603 4723-330A+P
R547 RMG, 1/16W, 33R, 1%, 0603 4723-330A+P
R550 RMG, 1/16W, 47K, 1%, 0603, HK, RESISTOR/, SAMSUNG 4723-473A+P-R
R551 RMG, 1/16W, 10K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-103A+P-R
R552 RMG, 1/10W, 0R, 5%, 0805 4720-000J+J
R553 RMG, 1/10W, 0R, 5%, 0805 4720-000J+J
R554 RMG, 1/10W, 0R, 5%, 0805 4720-000J+J
R555 RMG, 1/10W, 0R, 5%, 0805 4720-000J+J
R556 RMG, 1/16W, 0R, 1%, 0603 4723-000A+P
Capacitors
Reference
Designator
Description Vendor Part Number Note
C401 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C402 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C403 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C404 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C405 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C406 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C407 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C408 CC, 6.3V, 22U, 10%, 1206, 3.2X1.6 150B-226K+6-CF
C409 CC, 6.3V, 22U, 10%, 1206, 3.2X1.6 150B-226K+6-CF
C410 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C411 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C412 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C413 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C414 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C415 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C416 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C417 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C418 CC, 6.3V, 10U, 10%, 0805, X5R 150B-106K+J-BD
C419 CC, 25V, 10U, 10%, 1206, 3.2X1.6, X5R 150E-106K+6-CF
C420 CC, 100V, 0.1U, 10%, 0805, X7R 150H-104K+J-BD
C421 CC, 50V, 4700PF, 10%, 0603, X7R 150F-472K+P-AC
C422 CT, 16V, 10U, 20%, SMD, 1.6X3.2 154D-106M+3-CF
C423 CE, 25V, 220U, 20%, SM, 8.4X10, LOW ESR, LELON 157E-227M+3-PSR5
C424 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C426 CC, 50V, 1U, 10%, 0805 150F-105K+J-BD
C427 CT, 6.3V, 47U, 10%, SMD, 85C, 1.6X3.2 154B-476K+3-CF
