Bose PowerShare PS404A User Manual

78
Integrated Circuits (continued)
ELECTRICAL PART LIST
AmpLink PCB Assembly, PS604A Amplier
Reference
Designator
Description Vendor Part Number Note
U410 IC, XL208-256-TQ64-C10, MC, U, 32-BIT, HI, PWR, TQFP64 3133-1411+0-64
U411 IC, SN74LVC3G34DCUR, BUFFE, R, TRIPLE, VSSOP8 3133-1431+0
U412 IC, LM3674MF-ADJ, REG, SW, 5.5V, ADJ, 0.6A, SOT-23 3133-1391+0
U413 IC, CD74HC4094, SHIFT, REG, 8BIT, SIPO, 33NS, SO16 3132-4431+0
U414 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831+0
U415 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831+0
U416 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831+0
U417 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831+0
U418 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831+0
U419 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831+0
U420 IC, W25X20CLSNIG, FLASH, 2MBIT, SO8 3133-1401+0-30
U421 IC, TL432BIDBZR, REG, V-REF, 2.5-36V, SOT-23 3132-7691+0-16
U422 IC, CS2100CP-CZZ, PROG, CLOCK, 3.5V, MSOP10 3133-1621+0
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
J400 FFC, CONN., 30PIN, P1.0, TOP, ENTRY 2101-3073+0
J401 BRACKET, GROUNDING 4132-6221+0
J402 BRACKET, GROUNDING 4132-6221+0
J403 WAFER, 10, PIN, P2 2102-100S+003
J404 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376+1
J405 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376+1
J406 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376+1
J407 CONNECTOR, HEADER, 7P, P2.54, ST, M, SINGLE, BODY 2101-3297+0
J408 HEADER, 2X3P, P2.54, ST, MALE 2101-3124+0
J409 12P, ST., WAFER, P=2.5, COULOMB 2102-121S+004
J410 RJ45, F, 8P8C, 21.1X15.9X, 13.35, W/LED, S-USA 2113-3481+0
J411 RJ45, F, 8P8C, 21.1X15.9X, 13.35, W/LED, S-USA 2113-3481+0
T400 CHOKE, COMMODE, 90R@100MHZ, 100MA, 1.1R, SMD 0504 1805-0700+0
T401 CHOKE, COMMODE, 90R@100MHZ, 100MA, 1.1R, SMD 0504 1805-0700+0
T402 CHOKE, COMMODE, 90R@100MHZ, 100MA, 1.1R, SMD 0504 1805-0700+0
T403 CHOKE, COMMODE, 90R@100MHZ, 100MA, 1.1R, SMD 0504 1805-0700+0
T404 CHOKE, COMMODE, 90R@100MHZ, 100MA, 1.1R, SMD 0504 1805-0700+0
T405 CHOKE, COMMODE, 90R@100MHZ, 100MA, 1.1R, SMD 0504 1805-0700+0
X400 CRYSTAL, 12MHZ, -40+85, C, SMD 2300-2430+0
X401 CRYSTAL, 24.576MHZ, +/-25PPM, 7.0X5.0X1.5, SM 2300-3323+0

Bose PowerShare PS404A Specifications

General

Purpose	-
On/off switch	Yes
Product color	Black
Connectivity technology	Wired
Audio output channels	4.0 channels
Peak power per channel	400 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.04 %
Ethernet LAN (RJ-45) ports	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	14 W

Weight and Dimensions

Depth	414 mm
Width	483 mm
Height	44 mm
Weight	6400 g
