82
DISASSEMBLY PROCEDURE
13. Rear Panel PCB Removal
13.1 Perform procedure 1.
13.2 Disconnect the ribbon cable at J406 on the
AmpLink PCB. Disconnect the wiring harness at
J300 on the amplier PCB’s.
13.3 On the rear of the chassis, remove the twelve
screws that secure the rear panel PCB to the
chassis. Lift out the rear panel PCB.
14. Rear Panel Output PCB Removal
14.1 Perform procedure 1.
14.2 Disconnect the wiring harness at J300 on the
amplier PCB’s.
14.3 Remove the four screws that secure the rear
panel output PCB to the rear panel PCB and the
chassis. Lift off the rear panel output PCB.
15. IEC AC Input Jack Removal
15.1 Perform procedure 1.
15.2 Make a note of the wiring conguration, and
disconnect the AC wiring harness Faston connectors
from the three lugs on the IEC connector.
15.3 On the rear of the chassis, remove the two
screws that secure the IEC connector to the chassis.
Lift out the IEC connector.
