Bose PowerShare PS604D User Manual

English • 13Installation Guide • PowerShare PS604D/PS404D
pro.Bose.com
Installation
Technical Considerations:
When a loudspeaker EQ is selected in ControlSpace Designer, the appropriate crossover and V
Pk
and V
RMS
limiters for that loudspeaker are automatically loaded.
Adjusting the Output Attenuation control of a single channel does not aect the level of other channels. The
only exception is if the amplifier is attempting to deliver more than the total amplifier wattage. If the total
amplifier power is exceeded, the amplifier will limit all outputs simultaneously and equally until the demand
is reduced. If the demand remains too high, the amplifier will gradually limit to an average of 200 watts
continuously.
There are multiple ways to adjust output power in a PowerShare amplifier application:
Adjust input signal level relative to the sensitivity setting of the amplifier.
Adjust the Matrix level in ControlSpace Designer.
Adjust the Out levels in ControlSpace Designer.
Adjust the Output Attenuation controls of the amplifier.
Adjust the CC-D ControlCenter digital zone controller(s) settings.
Adjust the limiter settings for each output using ControlSpace Designer software.
Adjust the transformer tap settings of any connected Hi-Z loudspeakers.

Bose PowerShare PS604D Specifications

General

Purpose	Performance/stage
On/off switch	Yes
Product color	Black
Connectivity technology	Wired
Amplifier class	A
Output impedance	4 - 8 Ω
Input sensitivity	4 mV
Audio input channels	4.0 channels
Peak power per channel	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.04 %
Ethernet LAN (RJ-45) ports	1
Speakers connectivity type	-
LED indicators	Link, Network, Power
Maximum current	14.14 A
AC input voltage	100 - 240 V
Power consumption (standby)	14 W
Harmonized System (HS) code	85184000

Weight and Dimensions

Depth	414 mm
Width	483 mm
Height	44 mm
Weight	6400 g
