54
|
ENGLISH
TECHNICAL INFORMATION
SPECIFICATION DESCRIPTION
Headphone sensitivity
92dB SPL measure at 1 mW input signal, 1 kHz, in Mono mode
Headphone impedance
Mono mode: 300 Ohms ON and OFF
Stereo mode: 600 Ohms ON and OFF
Headphone frequency
response
RTCA-214a range: 300 to 3500Hz
Extended range: 40Hz to 15kHz
Boom microphone
sensitivity
-27dBV (+/- 2.5dB) at 94dB SPL (1 Pa), measured at 6mm
distance from artificial mouth, across 220 Ohms load resistor
and biased with 12 Vdc via 470 Ohms resistor.
Boom microphone bias Operating bias voltage range: 4 to 28 VDC.
Maximum ambient
noise level
105 dBC SPL for full active noise reduction performance
Battery power source Two (2) AA alkaline batteries
Battery life
45 hours in typical commercial jet aircraft noise. Duration
varies with battery age, ambient noise levels, temperature,
ear tip condition, and use of the Bluetooth feature.
Aircraft power source Aircraft power voltage range: 10 to 32 VDC
Average power consumption 250mW
Fuse/breaker recommended
1/4 amp, fast-blow fuse (AGC 1/4 amp fuse) or 1/2 amp circuit
breaker
Headset weight 10.6 ounces, 4.9 ounces on head
Headset size range
Slider not extended:
8.425" (214mm) H x 6.34" (161mm) W x 3.15" (80mm) D
Slider extended:
10.2" (259mm) H x 6.6" (168mm) W x 3.15" (80mm) D
Control module dimensions 1.5" (38.1mm) H x 1.5" (38.1mm) W x 4.92" (125mm) D
