Bose S1 PRO+ Service Manual

24
POWER PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R44, R47-R48, R110 RES, THICK FILM, 0603, 0.1W, 1%, 100K 801706-1003F
R49-R50, R52-R53 RES, THICK FILM, 1206, 0.25W, 1%, 825K 806729-8253F 3
R5, R11, R16, R113,
R127-R129, R172-R173
RES, THICK FILM, 0402, 0.063W, 1%, 100K 801703-1003F
R51,R54 RES,THICK FILM,1206,0.25W,1%,1M 806729-1004F
R55-R56, R61-R62, R75,
R179
RES, THICK FILM, 1206, 0.25W, 1%, 10 OHM 806730-10R0F
R57-R60, R63-R66 RES, THICK FILM, 1206, 0.25W, 1%, 56K 806729-5602F 3
R67 RES, THICK FILM, 0805, 0.125W, 1%, 47K 802354-4702F
R68-R69 RES, THICK FILM, 1206, 0.25W, 1%, 2.2K 806729-2201F
R7, R13, R20 JUMPER, CHIP, 0603 806732-0603
R70, R159-R160,
R165-R169
RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
802354-1000F
R72, R77, R154,
R180-R182
JUMPER, CHIP, 1206 806732-1206
R73 RES, THICK FILM, 0603, 0.1W, 1%, 100 OHM 801706-1000F
R74, R90 RES, THICK FILM, 0603, 0.1W, 1%, 10K 801706-1002F
R76 RES, THICK FILM, 0603, 0.1W, 1%, 470 OHM 801706-4700F
R78 RES, THICK FILM, 1206, 0.25W, 1%, 1 OHM 806730-1R00F
R79-R83 RES, THICK FILM, 1206, 0.25W, 1%, 1.3 OHM 806730-1R30F
R84 RES, THICK FILM, 0603, 0.1W, 1%, 2.7K 801706-2701F
R85 RES, THICK FILM, 0603, 0.1W, 1%, 510 OHM 801706-5100F
R87, R89, R171 RES, THICK FILM, 0603, 0.1W, 1%, 1K 801706-1001F
R88 RES, THICK FILM, 0603, 0.1W, 1%, 91K 801706-9102F
R91 RES, THICK FILM, 0603, 0.1W, 1%, 300K 801706-3003F
R92 RES, THICK FILM, 0805, 0.125W, 1%, 1 OHM 802355-1R00F
R94, R116 RES, METAL FOIL, 1206, 1W, 1%, 0.005 OHM 755170-R005F
R95 RES, THICK FILM, 0603, 0.1W, 1%, 10 OHM 801707-10R0F
R96, R121 RES, THICK FILM, 0402, 0.063W, 1%, 10 OHM 801704-10R0F
R98 RES, THICK FILM, 0603, 0.1W, 1%, 120K 801706-1203F
R99 RES, THICK FILM, 0402, 0.063W, 1%, 12K 801703-1202F
RT1, RT3-RT4 THERMISTOR, NTC, 0402, 4250K, 1%, 100K 790375-104 3
RT2 THERMISTOR, NTC, ICL, BULK, 20%, 10 ohm 856032-100MB 3

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
