Bose S1 PRO+ Service Manual

25
POWER PCB PARTS LIST
Capacitors
Reference Designator Description Material Number Note
C1, C3-C4, C7, C9, C12,
C15, C18, C72-C73,
C76-C77, C96, C118-C119,
C122, C125-C128,
C137-C138, C141-C143,
C159-C164, C176
CAP, X7R, 0402, 50V, 10%, 0.1uF, COMM 718866-104K1H
C102, C117, C124, C130,
C132, C144-C146, C156,
C165-C166
CAP, X5R, 0805, 50V, 10%, 4.7uF, COMM 743447-475K1H
C110 CAP, EL, SMT, 105C, 50V, 20%, 220uF, COMM 856752-221M1HED
C123 CAP, C0G, 0402, 50V, 5%, 1000pF, COMM 766718-102J1H
C136 CAP, C0G, 0603, 50V, 5%, 22pF, COMM 780788-220J1H
C140 CAP, X5R, 0402, 10V, 10%, 1uF, COMM 716994-105K1A
C152-C155, C168 CAP, C0G, 0402, 50V, 5%, 220pF, COMM 766718-221J1H
C16, C20-C21, C27-C28,
C30, C50-C55, C109, C151,
C183
CAP, X7R, 0402, 50V, 10%, 2200pF, COMM 718866-222K1H
C17 CAP, X5R, 0805, 25V, 10%, 10uF, COMM 743447-106K1E
C171, C175 CAP, EL, SMT, 105C, 35V, 20%, 4.7uF, COMM 856752-4R7M1VAA
C172 CAP, C0G, HI VOLT, 1206, 1000V, 5%, 150pF,
COMM
777098-151J3A
C179 CAP, X5R, 0603, 16V, 10%, 2.2uF, COMM 718835-225K1C
C19, C22, C45, C47, C112 CAP, X7R, 0402, 50V, 10%, 0.033uF, COMM 718866-333K1H
C2, C10-C11, C25, C32,
C56-C67, C104-C107,
C114-C116, C134, C139
CAP, X7R, 0603, 50V, 10%, 1uF, COMM 718875-105K1H
C23, C34, C37, C46, C101,
C121, C131
CAP, X7R, 0603, 50V, 5%, 10000pF, COMM 718875-103J1H
C24, C26, C31, C33,
C39-C40, C43-C44, C103,
C111, C173
CAP, C0G, 0603, 50V, 5%, 1000pF, COMM 780788-102J1H
C29, C35-C36, C41 CAP, EL, SMT, 105C, 16V, 20%, 10uF, COMM 856752-100M1CAB
C38, C42 CAP, FILM, LS 5mm, AMMO, 5%, 100V, 1uF 329288-1004BJA
C48-C49 CAP, X5R, 0402, 25V, 10%, 1uF, COMM 716994-105K1E
C5, C74-C75, C120, C150 CAP, X7R, 0402, 50V, 10%, 10000pF, COMM 718866-103K1H
C6 CAP, C0G, 0402, 50V, 5%, 330pF, COMM 766718-331J1H
C70, C83-C84, C108, C135,
C147-C149, C157-C158,
C167, C169-C170, C174
CAP, C0G, 0402, 50V, 5%, 100pF, COMM 766718-101J1H
C71, C133, C180-C182 CAP, C0G, 0603, 50V, 5%, 220pF, COMM 780788-221J1H
C78-C80 CAP, X7R, HI V, FT, 1210, 500V, 10%, 0.1uF,
COMM
852058-104K2H
C8, C68-C69, C91-C92 CAP, EL, LOW Z, SMT, 35V, 20%, 470uF,
COMM
856727-471M1VDE
C81-C82 CAP, EL, 18x25mm, 105C, 450V, 20%, 82uF 872481-820M2WGF 3

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
