Bose S1 PRO+ Service Manual

26
POWER PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C85 CAP, X7R, HI VOLT, 0805, 500V, 10%, 470pF,
COMM
852020-471K2H
C86-C87 CAP, X7R, HI V, 1206, 1000V, 10%, 4700pF,
COMM
852057-472K3A
C88-C90, C100, C113,
C129, C177-C178
CAP, X7R, 0603, 50V, 10%, 0.1uF, COMM 718875-104K1H
C93-C94 CAP, X7R, HI V, 1206, 1000V, 10%, 1000pF,
COMM
852057-102K3A
C95 CAP, EL, POLYMER, SMT, 25V, 20%, 47uF,
COMM
857020-470M1EAA
C97-C99 CAP, C0G, 0603, 50V, 5%, 100pF, COMM 780788-101J1H
Diodes
Reference Designator Description Material Number Note
BD1 DIODE, BRIDGE, RECT, 8A, 800V, GBU806 873672-0800 3
D12, D14, D16-D17 DIODE, SWITCHING, 100V, 0.15A, SOD323F 856395-0010
D13, D19 DIODE, RECTIFIER, BARRIER, 40V, 3A, SB-
R3U40
861704-0010
D15, D20 DIODE, SWITCHING, 90V, 225mA, SOD-323 842754-0010
D22 DIODE, TVS, BIDIR, DUAL, 25V, SOT23, AUTO 855760-0010
D24 DIODE, SW, 75V, 0.3A, SOT-23, BAV99 747976-0010
D25 DIODE, SCHOTTKY, 30V, BAT54A, SOT-23 330427-0020
D2-D3, D21 DIODE, SCHOTTKY, 2A, 60V, SOD123F 852398-0010
D4-D5, D26-D27 DIODE, TVS, BIDIR, 5V, D5V0X1B2LP, 2DFN 859878-0020
D6-D7, D11 DIODE, RECT, FAST, 1000V, 0.8A, RS1ML,
FLSMA
856386-1000
D8 DIODE, RECT, S-FAST, 400V, 10A, TPMR10G,
SMPC
855873-0400
D9 DIODE, RECT, FAST, 1000V, 1A, RS1M, SMA 873679-1000
DIODE, ZENER, 0.2W, 15V, 5%, SOD-323 883107-15V0
CX1-CX2 CAP, FILM, X2, LS 15mm, 305VAC, 20%,
0.47uF
310415-474MG
3
CY1-CY2 CAP, CER, X1/Y1, Bulk 5mm, 20%, 1000pF 855444-102MN
CY3, CY5-CY6 CAP, CER, X1/Y1, AMMO PACK, 10%, 330pF 855444-331KV 3

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
