Bose S1 PRO+ Service Manual

43
TEST PROCEDURE
8 Reset the system
8.1 Press and hold the Power button for 10
seconds until the power light turns o󰀨 and a
message appears on the channel displays.
8.2 The system reboots.When the reset is
complete, the power light glows solid white.
Note:
a. You can restore your channel and system
settings after a system reset using the Bose
Music app.
b. The rst step to troubleshooting should
be to perform a full system reset to ensure a
consistent starting point.
8.3 Update the system
To check for and download system software
updates, use your computer to visit the
Bose updater website at: btu.Bose.com
For more detailed instructions, visit: support.
Bose.com/S1ProPlusUpdate
9 Reset a wireless transmitter
9.1 Press and hold the Power button for 10
seconds until the power light turns o󰀨.
9.2 Update a wireless transmitter
When you insert a wireless transmitter into
either of the wireless transmitter charging ports,
the system checks whether a software update
is available. If it is, follow the instructions on the
channel display to install the update.
10 Charge your mobile device using the USB
charging port
10.1 Connect one end of a USB-A charging
cable (not provided) to the USB POWER
port on the system.
10.2 Connect the other end to your mobile
device.

Bose S1 PRO+ Specifications

General

Type	Handheld Public Address (PA) system
Handle(s)	Yes
Product color	Black
Housing material	Aluminium, Polypropylene (PP)
Storage temperature (T-T)	-20 - 49 °C
Operating temperature (T-T)	0 - 45 °C
Bluetooth range	9 m
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	2
Charging time	5 h
AC input voltage	100 - 240 V
Battery capacity	5500 mAh
Power source type	AC, Battery
AC input frequency	50/60 Hz
Battery life (max)	11 h
Number of mixer channels	3 channels
Speaker type	2-way
Number of speakers	-
Frequency range	- Hz
RMS rated power	- W

Weight and Dimensions

Depth	279.8 mm
Width	240 mm
Height	332.6 mm
Weight	6500 g
