Bose SoundTouch SA-5 User Manual

20 - ENGLISH
WIRED CONNECTIONS
Connect to the AUX IN connector
You can connect the audio output of a smartphone, tablet, computer or other type of
audio device to your amplifier’s AUX IN connectors. The amplifier accepts 3.5 mm plugs
(not provided) or RCA (red and white) plugs (not provided).
1. Using a stereo cable, connect your audio device to one of the AUX connectors on
the amplifier.
2. From within the app, select your amplifier from the device tray.
3. Select AUX.
4. Select your AUX source to play music.
5. Start playing music on the mobile device.

Bose SoundTouch SA-5 Specifications

General

Amplifier class	-
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
AC (power) in	Yes
USB 2.0 ports quantity	1
Purpose	Home
Product color	Black
Connectivity technology	Wired & Wireless

Weight and Dimensions

Depth	300 mm
Width	184 mm
Height	77 mm
Weight	1500 g
