Bose SoundTouch SA-5 User Manual

24 - ENGLISH
CARE AND MAINTENANCE
Technical information
Dimensions and Weight
• 7
1
⁄4 in. wide x 12 in. deep x 3 in. high (18.4 cm x 30.0 cm x 7.7 cm)
• 3.3 lb (1.5 kg)
Power rating
100-240V 50/60 Hz, 400W
Input sensitivity
• 3.5 mm input: 1Vrms
• RCA inputs: 2Vrms
Signal to Noise ratio (S/N)
>100 dB
Output power (continuous average)
100W / channel minimum into 8 ohms, from 20 Hz to 20 kHz, with no more than
0.6% THD.
Temperature range
32° F to 104° F (0° C to 40° C)

Bose SoundTouch SA-5 Specifications

General

Amplifier class	-
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
AC (power) in	Yes
USB 2.0 ports quantity	1
Purpose	Home
Product color	Black
Connectivity technology	Wired & Wireless

Weight and Dimensions

Depth	300 mm
Width	184 mm
Height	77 mm
Weight	1500 g
