Boss Space Echo RE-202 - Page 19

Various Settings
19
Setting
[MODE
SELECTOR]
knob
Value
Indicators
that are lit
Explanation
7
MEMORY: 2,
HEAD: 2
CH. 7
8
MEMORY: 3,
HEAD: 2
CH. 8
9
MEMORY: 4,
HEAD: 2
CH. 9
10
MEMORY:
MANUAL,
HEAD: 3
CH. 10
11
MEMORY: 1,
HEAD: 3
CH. 11
12
MEMORY: 2,
HEAD: 3
CH. 12
13
MEMORY: 3,
HEAD: 3
CH. 13
14
MEMORY: 4,
HEAD: 3
CH. 14
15
MEMORY:
MANUAL,
HEAD: 4
CH. 15
16
MEMORY: 1,
HEAD: 4
CH. 16
RX
MEMORY: 2,
HEAD: 4
Transmits on the same channel as the RX CHANNEL.
Receive program
change message
(PC IN)
8
ON
MEMORY:
MANUAL
Program change messages are received.
OFF
MEMORY: 1
Program change messages are not received.
Transmit program
change messages
(PC OUT)
9
ON
MEMORY:
MANUAL
Program change messages are transmitted.
OFF
MEMORY: 1
Program change messages are not transmitted.
Receiving control
change message
(CC IN)
10
ON
MEMORY:
MANUAL
Control change messages are received.
OFF
MEMORY: 1
Control change messages are not received.
Transmit control
change messages
(CC OUT)
11
ON
MEMORY:
MANUAL
Control change messages are transmitted.
OFF
MEMORY: 1
Control change messages are not transmitted.
MIDI clock sync
(SYNC)
12
INTERNAL
MEMORY:
MANUAL
Operations are synchronized to the RE-202’s internal
clock.
AUTO
MEMORY: 1
Operations are synchronized to the MIDI clock received
via MIDI. However, operations are automatically
synchronized to the RE-202’s internal clock if the unit is
unable to receive the external clock.
REALTIME
SOURCE
1
INTERNAL
MEMORY:
MANUAL
Internal real-time messages are used as the clock source.
MIDI
MEMORY: 1
Real-time messages from the MIDI IN connector are used
as the clock source.
MIDI THRU
2
ON
MEMORY:
MANUAL
Specifies whether MIDI messages received at the MIDI IN
connector are retransmitted as-is from the MIDI OUT
connector (ON) or are not retransmitted (OFF).
OFF
MEMORY: 1
DEVICE ID
3
17
MEMORY:
MANUAL,
HEAD: 1
This sets the MIDI Device ID used for transmitting and
receiving Exclusive messages.
18
MEMORY: 1,
HEAD: 1
19
MEMORY: 2,
HEAD: 1
20
MEMORY: 3,
HEAD: 1
21
MEMORY: 4,
HEAD: 1
22
MEMORY:
MANUAL,
HEAD: 2
