Main Specifications
23
Main Specifications
AD Conversion
* AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that
vastly improves the signal-to-noise (SN) ratio of the AD converter.
INPUT A/MONO, INPUT B: -10 dBu
INPUT A/MONO, INPUT B: +7 dBu
INPUT A/MONO, INPUT B: 1 M ohm
OUTPUT A/MONO, OUTPUT B: -10 dBu
OUTPUT A/MONO, OUTPUT B: +7 dBu
OUTPUT A/MONO, OUTPUT B: 1 k ohm
Recommended Load
Impedance
OUTPUT A/MONO, OUTPUT B: 10 k ohms or greater
Controls
ON/OFF switch, MEMORY switch, TAP switch
SATURATION knob, WOW & FLUTTER knob, MODE SELECTOR knob, BASS knob, TREBLE knob, REVERB
VOL knob, REPEAT RATE knob, INTENSITY knob, ECHO VOL knob
MEMORY button, INPUT button, TAPE button
Connectors
INPUT A/MONO jack, INTPUT B jack, OUTPUT A/MONO jack, OUTPUT B jack: 1/4-inch phone type
CTL 1, 2/EXP jack: 1/4-inch TRS phone type
MIDI (IN, OUT) jacks: Stereo miniature phone type
DC IN jack
USB port: USB micro B-type (program update only)
Dimensions
192 (W) x 133 (D) x 52 (H) mm / 7-9/16 (W) x 5-15/64 (D) x 2-3/64 (H) inches
192 (W) x 133 (D) x 53 (H) mm / 7-9/16 (W) x 5-15/64 (D) x 2-3/32 (H) inches (including rubber foot)
Weight (including
battery)
Accessories
Owner's Manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Options (sold
separately)
Dual footswitch: FS-6, FS-7
Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
MIDI/TRS connecting cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535
* 0 dBu = 0.775 Vrms
* This document explains the specifications of the product at the time that the document was issued. For the latest
information, refer to the Roland website.
