Bostitch BCN662 - Troubleshooting Charging Issues (Continued); Tool Specifications; Nailer Specifications; General Tool Dimensions

ENGLISH
8
c. Move the charger and battery pack to a location
where the surrounding air temperature is
approximately 65°F – 75°F (18° – 24°C);
d. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
4. The battery pack should be recharged when it fails to
produce sufficient power on jobs which were easily
done previously. DO NOT CONTINUE to use under these
conditions. Follow the charging procedure. You may
also charge a partially used pack whenever you desire
with no adverse effect on the batterypack.
5. Foreign materials of a conductive nature such as, but
not limited to, grinding dust, metal chips, steel wool,
aluminum foil, or any buildup of metallic particles
should be kept away from charger cavities. Always
unplug the charger from the power supply when there
is no battery pack in the cavity. Unplug the charger
before attempting toclean.
6. Do not freeze or immerse the charger in water or any
otherliquid.
Storage Recommendations
1. The best storage place is one that is cool and dry, away
from direct sunlight and excess heat orcold.
2. For long storage, it is recommended to store a fully
charged battery pack in a cool dry place out of the
charger for optimalresults.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be
recharged beforeuse.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
COMPONENTS (FIG. A)

WARNING: Never modify the power tool or any part
of it. Damage or personal injury couldresult.
Refer to Figure A at the beginning of this manual for a
complete list ofcomponents.
Intended Use
Your cordless straight nailer has been designed for driving
nails into woodenworkpieces.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
Your cordless straight nailer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Tool Specifications
Firing Mode Selectable: Sequential or Bump
Voltage 20
Height 12.3" (31.2 cm)
Width 3.7" (9.3 cm)
Tool Specifications
Length 11.8" (29.9 cm)
Weight (without battery) 5.6 lbs (2.5 kg)
Magazine Angle Straight
Loading Capacity 100 nails
Nail Specifications
Straight Nail Lengths 1 1/4" - 2 1/2" (32 mm - 64 mm)
Shank Diameters 16 gauge
Nail Stick Angles Straight
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can causeinjury.
Belt Hook (Fig. D)

WARNING: Remove nails from magazine before
making any adjustments or servicing this tool.
Failure to do so may result in seriousinjury.

WARNING: Disconnect battery pack from tool
before making any adjustments, changing
accessories, servicing, or moving the tool. Such
preventative safety measures reduce the risk of
starting the toolaccidentally.

CAUTION: When not in use, place tool on its side
on a stable surface where it will not cause a
tripping or falling hazard. Some tools with large
battery packs will stand upright on the battery pack
but may be easily knockedover.
The cordless nailers include an integrated belt hook
9
and
can be attached to either side of the tool to accommodate
left- or right-handedusers.
If the hook is not desired at all, it can be removed from
thetool.
Fig. D
9
17
To Remove Belt Hook
1. Remove battery pack fromtool.
2. To switch the tool from right- to left-hand usage simply
remove the screw
17
from the opposite side of the tool
and reassemble on the otherside.
3. Replace batterypack.
